Iluv i110 User Manual

The device complies with part 15 of Fcc Rules .Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may cause undesired operation

The changes or modifications not expressly approved by the party responsible for compliance could void the user's

authority to operate the equipment.

1、

SPECIFICATION。

Bluetooth Core: Bluetooth V1.2 compliant

Bluetooth Profile: A2DP, AVRCP

Operating Frequency: 2.4-2.4835GHz

Security Features: 128-bit Encryption

Transmitting Rate: 721Kbps (Max)

Wireless Technology: FHSS

Communication Distance: Class 2, up to 33ft (10m)

Brief Introduction of Functions.

i110 Bluetooth Dongle has two operating modes：TX and RX。It has a mode selection switch for shifting modes

and a pairing button for operating pairing.

TX is transmitting mode. By Bluetooth, it can transmit the analog audio signals from acoustic mainframe to other

Bluetooth receiving devices (e.g. Bluetooth stereo headset).

RX is receiving mode. It can receive stereo music from Bluetooth devices, which support A2DP profile (e. g. PC

or Mobile phone supporting Bluetooth). Meanwhile, it can amplify and output the music through acoustic

mainframe.

2、

i110 User's Manual

Table of Contents

Do you have a question about the i110 and is the answer not in the manual?

Page 1 Communication Distance: Class 2, up to 33ft (10m) Brief Introduction of Functions. i110 Bluetooth Dongle has two operating modes：TX and RX。It has a mode selection switch for shifting modes and a pairing button for operating pairing. TX is transmitting mode. By Bluetooth, it can transmit the analog audio signals from acoustic mainframe to other Bluetooth receiving devices (e.g.
Page 2 Long-press is 3 seconds. 4. TX Mode. Plug i110 to mainframe and make it electrified, it will come in default standby mode. Then the blue LED will flash slowly. Long press pairing button in pairing state, then pair and connect it with other Bluetooth stereo audio receiving devices (e.g., Bluetooth headset) until red and blue LED blinking alternately.
Page 3 1) Ill0 can only connect Bluetooth stereo devices with pin code “0000”, not Bluetooth stereo device with other pin code. 2) When ill0’s red light is long on, it indicates that the internal program has error. Just pull i110 out of acoustic mainframe and plug it in again, and then it will be ok.
