HS-A1
Getting Started Guide

Introduction

The HS-A1 is an analog handset with an armored cable and a hook switch
mechanism designed to be connected to an IP7 intercom module to enable full
duplex audio operations with a TalkMaster operator console or SIP Phone.
The HS-A1 can place a call by removing the handset from the switch hook. If
configured for TalkMaster, it will place an Incoming Call. If the IP7 is
configured to dial out to a SIP Extension, it will initiate a call to the specified
phone number.
If the HS-A1 is called from TalkMaster or from a SIP phone, the internal piezo
buzzer will sound to indicate there is an incoming call. The HS-1A must be
connected to either an IP7-SE8 or IP7-FD IP Module.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HS-A1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Digital Acoustics HS-A1

  • Page 1 IP7 intercom module to enable full duplex audio operations with a TalkMaster operator console or SIP Phone. The HS-A1 can place a call by removing the handset from the switch hook. If configured for TalkMaster, it will place an Incoming Call. If the IP7 is configured to dial out to a SIP Extension, it will initiate a call to the specified phone number.
  • Page 2 Installation The Handsets are designed to be flush mounted in a 2-gang box. A 3-pair cable is used to connect the Handset to an IP7-SE8. On the back of the handset is a seven position 3.81mm DIN connector. The connection details are: J1-1 J1-7...
  • Page 3 Configuration TalkMaster FOCUS Software is a suite of Windows® based applications used to configure and manage Digital Acoustics IP Intercoms and Paging endpoints. TalkMaster FOCUS is available for download on the Digital Acoustics Website. The TalkMaster Server/Admin Console must be installed to configure IP Endpoints.
  • Page 4 • Click the Save button to save the changes to the Intercom IP7 and Digital Acoustics® are trademarks of Digital Acoustics LLC. Other trademarks are the property of their respective owners. HS-A1GSG - 2018-03-14 - All Rights Reserved ©2018 www.digitalacoustics.com/support...
