- Page 1 OWNER’S MANUAL CONDITIONER Please read this manual carefully before operating your set and retain it for future reference. SINGLE PACKAGE TYPE AIR CONDITIONER www.lg.com P/NO : MFL69466601...
-
Page 2: Table Of Contents
Single Package Air Conditioner Owner’s Manual TABLE OF CONTENTS FOR YOUR RECORDS Write the model and serial numbers here: Safety Precautions ....3 Model # Serial # You can find them on a label on the side of each unit. Operation Manual ....6 Dealer's Name Specification......7 Date Purchased... -
Page 3: Safety Precautions
Safety Precautions Safety Precautions To prevent injury to the user or other people and property damage, the following instructions must be followed. n Incorrect operation due to ignoring instruction will cause harm or damage. The seriousness is classified by the following indications. WARNING This symbol indicates the possibility of death or serious injury. - Page 4 Safety Precautions n Operation Do not let the air conditioner Take care to ensure that Do not place anything on the run for a long time when the power cable could not be power cable. humidity is very high and a pulled out or damaged dur- door or a window is left open.
- Page 5 Safety Precautions CAUTION n Installation Always check for gas (refriger- Install the drain hose to Keep level even when ant) pressure after installation ensure that water is drained installing the product. or repair of product. away properly. • To avoid vibration or water leak- •...
-
Page 6: Operation Manual
Operation Manual Operation Manual LK-C0728A / LK-C0908A Category Functions LK-C1058A Air supply outlet Air Flow Airflow steps(fan/cool/heat) 1/1/- Jet cool(Power wind) E.S.P. control Installation Electric heater(operation) Hot start Self diagnosis Soft dry operation Defrost / Deicing High pressure switch Reliability... -
Page 7: Specification
Operation Manual Specification Power Supply: 20VAC-30VAC 50-60 Hz or Battery powered. Terminal Load: 1.0 A per terminal, 3.0 A maximum total load Set Point Temperature Range: 45 °F to 90 °F (7 °C to 32 °C). Accuracy: +/- 1 °F or +/- 0.5 °C. Dimensions: 5.1"... -
Page 8: Thermostat Buttons And Switches
Operation Manual THERMOSTAT BUTTONS AND SWITCHES (1) Raises temperature setting (2) Lowers temperature setting (3) Time setting (4) Fan control switch (ON, AUTO) (5) System control switch (COOL, OFF, HEAT) Note : System control switch “HEAT” will not work. 8 Single Package Air Conditioner... - Page 9 Operation Manual Filter PRGM Heat cool Inside Setting Alam Run on Hold °F °C STATUS PRGM Heat on Setting Cool on SYSTEM Heat Cool On Auto (6) Filter Alarm; Indicates filter needs to be replaced. (7) Alarm when flashing, indicates a system malfunction (8) PRGM Run On: Indicates when the thermostat is ln the program RUN mode.
-
Page 10: Inserting The Batteries
Operation Manual INSERTING THE BATTERIES Attach thermostat base to wall pull the cover off the base. Screw anchors Reset Base Screw OPEN Cover Figure 1 Figure 2 Turn off power at the main service panel by removing the fuse or switching the appropriate circuit breaker to the OFF position before removing the existing thermostat 1. -
Page 11: Battery Operation
Operation Manual BATTERY OPERATION The thermostat is powered by 24VAC. Batteries are not required for proper operation, but with two "AAA" batteries installed, your thermostat will maintain time and continuously display the temperature during a loss of power. CHECK THERMOSTAT OPERATlON If at any time during testing your system does not operate properly, contact a qualified service person. -
Page 12: Configuration And Operation
Operation Manual CONFIGURATION AND OPERATION 1. Configuration Menu The configuration menu allows you to set certain thermostat operating characteristics to your system or personal requirements. Move the SYSTEM switch to the OFF position, then press and hold the ▲+▲ buttons for 5 sec- onds to enter the configuration menu. - Page 13 Operation Manual 1. Select cooling cycle rate The FA setting is used to produce shorter cooling cycles. The SL setting produces a longer cooling cycle. Both settings produce very accurate temperature control and can be set to your personal preference. FA cycles the system at a 0.5 °F (0-5 °C) differential, and Aux cooling at 2.0 °F high first stage on.
-
Page 14: Manual Operation
Operation Manual MANUAL OPERATION 1. CHECK COUNT BACK FOR FILTER REPLACEMENT a) When in configuration the selections are in months, each month selections are equal to 30 days. b) To review the remaining days hold the "F" button c) To reset the filter days - hold the "F" button (to enter the filter program) and then hold the ▲ or ▼ buttons. This resets the timer and starts counting the days until the next filter change. - Page 15 February, 2016...
