Summary of Contents for Meiya Pico CyberBlock SAS
- Page 1 CyberBlock SAS User Manual Meiya Pico Information Co., Ltd. All Rights Reserved July 2016...
-
Page 2: Table Of Contents
CyberBlock SAS User Manual Contents 1 PRODUCT INTRODUCTION ............1 Overview ................... 1 Features .................... 1 2 COMPONENTS ................. 2 Front Panel..................2 Rear Panel ..................3 Accessory ..................3 3 USAGE ....................5 Connecting a SAS HDD ..............5 Removing a Connected HDD ............ -
Page 3: Product Introduction
CyberBlock SAS User Manual Product Introduction Overview The CyberBlock SAS is used to provide write-protection for SAS devices. It blocks all inbound write commands at hardware level. This protects data in storage devices from being modified during acquisition and analysis, maintaining the judicial availability and data integrity for forensic investigations. -
Page 4: Components
CyberBlock SAS User Manual Components Front Panel The following figure shows the front panel of CyberBlock SAS ①. SAS interface. ②. Activity indicator, indicates whether the connected device is in read-write state. ③. Host indicator, indicates the connection state of the analysis computer. -
Page 5: Rear Panel
CyberBlock SAS User Manual Rear Panel The following figure shows the rear panel of CyberBlock SAS. ①. Power interface, provides power supply for CyberBlock SAS. ②. USB 3.0 interface, provides USB 3.0/2.0 connection to analysis computer. Accessory The following figure shows accessories of CyberBlock SAS. - Page 6 CyberBlock SAS User Manual ①. USB 3.0 data cable. ②. SAS data cable.
-
Page 7: Usage
2 Connect CyberBlock SAS to the analysis computer using USB 3.0 data cable. 3 Plug in the power cable of CyberBlock SAS and turn on the power switch. The Power, Host, and Activity indicators will flash, indicating the SAS HDD is connected to the analysis computer in... -
Page 8: Removing A Connected Hdd
1 Remove the HDD from the computer OS. For example, click to remove the HDD on Windows. 2 Switch off CyberBlock SAS and remove the original HDD. 3 Connect the new HDD to CyberBlock SAS and switch on CyberBlock SAS again. -
Page 9: Faq
Q1: Why cannot CyberBlock SAS detect the connected SAS HDD with some models of Macbook? It is necessary to connect the SAS HDD to CyberBlock SAS, turn on the power switch of CyberBlock SAS and then hot-plug the USB 3.0 data cable. - Page 10 CyberBlock SAS User Manual and select Change Drive Letter and Paths. Restart CyberBlock SAS and the partitions of the disk can be viewed.
-
Page 11: Technical Support
CyberBlock SAS User Manual Technical Support Tel: +86-592-2170918 Forum: https://bbs.meiyapico.com Skype: meiyapico@hotmail.com QQ Group: 261079328 Gmail: meiyapicots@gmail.com Whatsapp: +8618605926825 WeChat: MeiyaPicoTS Hardware version: V1.1 Document version: V1.1...
