LEVELe
ELEVATOR INTERIORS WITH LIGHTPLANE
®
TOOLS NEEDED
IMPACT
DRILL
3/8" DRILL
BIT
INCLUDED
STANDARD LEVELe COMPONENTS
PANEL
MOUNTING
CLIP
EXTRUSION
LIGHTPLANE COMPONENTS
LIGHTPLANE PANEL
POWER BOX
T 1.800.451.0410 | F 412.781.7840 | www.forms-surfaces.com
© 2017 Forms+Surfaces® | All dimensions are nominal. Specifications and pricing subject to change without notice. For the most current version of this document, please refer to our website at www.forms-surfaces.com.
CRESCENT WRENCH
#8-18 SQUARE / PHILIPS
COMBO DRIVE BIT
DRILL BIT
EXTENDER
TAPE
MEASURE
COVER
FRONT
EXTRUSION
REVEAL
CORNER
REVEAL
CEILING COMPONENTS
SUCTION
CUP(S)
PENCIL
CENTER
PUNCH
BASE CLEAT
BASE
SUPPORT
CEILING POWER BOX
INSTALLATION INSTRUCTIONS
MASKING TAPE
SQUARE
LEVEL
SPACER
#8 x 1/2"
SELF TAPPING SCREW
W/ #2 SQUARED
BASE
DRIVE HEAD
FACING
ALLEN
KEY
3/8" - 16
LOCKING DISC
U-BOLT
FLANGE NUT
page 1 of 7 | 10-16-17
BRUSH
Advertisement
Table of Contents
Summary of Contents for Forms + Surfaces levele
- Page 1 #8-18 SQUARE / PHILIPS COMBO DRIVE BIT PENCIL DRILL BIT EXTENDER CENTER BRUSH 3/8" DRILL PUNCH TAPE LEVEL MEASURE INCLUDED STANDARD LEVELe COMPONENTS SPACER #8 x 1/2" SELF TAPPING SCREW W/ #2 SQUARED BASE CLEAT BASE BASE DRIVE HEAD COVER FRONT FACING PANEL...
- Page 2 LEVELe ELEVATOR INTERIORS WITH LIGHTPLANE ® INSTALLATION INSTRUCTIONS STEP BY STEP Center of Side Wall Panels Masking Paper Template Tape Provided Cab Canopy Masking Tape Rear Corner Reveal Finished Floor Ceiling Location SIDE REAR Install (2) Corner Reveals. Temporarily attach provided paper template Drill holes to insert the U-bolts.
- Page 3 Cut zip ties and place leads on front of panel. should not obstruct wire exit locations, as • LEVELe LightPlane Panels are installed using the same steps as LEVELe panels. LightPlane indicated on LightPlane Panels. Panels have an attached, visible power lead. T 1.800.451.0410 | F 412.781.7840 | www.forms-surfaces.com ©...
- Page 4 LEVELe ELEVATOR INTERIORS WITH LIGHTPLANE ® INSTALLATION INSTRUCTIONS Panel Clip Panel 1 Panel 2 REAR SIDE SIDE REAR Attach lead to elevator interior wall. Install next Panel in sequence. Repeat steps 8-10 as required. • Attach the lead(s) to the wall with masking •...
- Page 5 LEVELe ELEVATOR INTERIORS WITH LIGHTPLANE ® INSTALLATION INSTRUCTIONS TOP VIEW Mounting Installed Extrusion Panel SIDE REAR SIDE REAR REAR SIDE Install Panel Clips. Repeat steps 18-19 as required. Install (1) Mounting Extrusion on remaining side of rear wall. • No side Panel Clips are installed for last •...
- Page 6 LEVELe ELEVATOR INTERIORS WITH LIGHTPLANE ® INSTALLATION INSTRUCTIONS 4" Connect power source to LightPlane Attach U-bolts to elevator shell. Hang ceiling from U-bolts. panel lead(s). Attach U-Bolt using provided retainer Lift ceiling, engaging U-Bolts into • • clip, washers and 3/8" - 16 flange nut.
- Page 7 LEVELe ELEVATOR INTERIORS WITH LIGHTPLANE ® INSTALLATION INSTRUCTIONS Base Cleat Base Base Facing Support SIDE VIEW REAR SIDE Connect Ceiling Power Box to local power. Install Base Facing. • Remove the cover from the power box. • Complete the installation by installing the •...
