INHALO ® Integrated delivery of therapeutic gas Step by step Operating guidelines lighter safer robust reliable BOC: Living healthcare...
Page 2
Step by step operating guidelines – INHALO ® Summary The product label is fixed to the cylinder collar and contains information such as gas code, UN number, cylinder size, cylinder contents, cylinder capacity, safe handling notes, and safety precautions relating to the gas contents.
Page 3
Step by step operating guidelines – INHALO ® Summary The contents gauge is easy to read and provides a clear indication of when the cylinder is full (green zone), in between (1/4, 1/2, 3/4), or when you should consider changing (red zone). The...
Page 4
Step by step operating guidelines – INHALO ® Summary The flow selector knob is designed for maximum grip and ease of use, it is used in conjunction with the firtree outlet and the OPEN/CLOSE hand wheel deliver variable gas flow (0 – 15 lpm). The...
Page 5
Step by step operating guidelines – INHALO ® Summary The tamper evident seal ensures quality, and when removed provides access to the OPEN/CLOSE hand wheel. Grasp the pull ring and simply remove the tamper evident seal as shown. These covers are recyclable, please discard thoughtfully.
Page 6
Step by step operating guidelines – INHALO ® Summary To access the gas outlet ports open the cover as shown. Simply swing the cover Open the light grey hinged down allowing it to stay attached at the cover which protects the firtree hinge where possible.
Page 7
Step by step operating guidelines – INHALO ® Summary Connect After you have checked that the flow Firtree outlet: selector is set to zero attach therapy This outlet is for connecting therapy tubing, mask or cannulae directly to the tubing, mask or canulae to the firtree outlet.
Page 8
Step by step operating guidelines – INHALO ® Summary The DIO outlet is used in conjunction with the OPEN/CLOSE hand wheel to deliver gas (4 Bar) to equipment attached to the DIO. Gas Connect will not flow from the DIO unless equipment is attached to it.
Page 9
Step by step operating guidelines – INHALO ® Summary The OPEN/CLOSE hand wheel is used to provide gas to both the firtree outlet once a flow setting has been selected, and the DIO outlet once equipment has been attached. The firtree & DIO outlets work independently of each other.
Page 10
Step by step operating guidelines – INHALO ® Summary The flow selector is used in conjunction Rotate the gas flow selector with the firtree outlet and the OPEN/ knob to the desired flow rate CLOSE hand wheel to deliver variable for your application.
Page 11
Step by step operating guidelines – INHALO ® After use. Depressurise equipment. Set flow selector to zero. Slowly close the OPEN/CLOSE hand wheel by rotating in a clockwise direction until it stops, as illustrated. Remove equipment and tubing, replace grey cover where possible BOC: Living healthcare and return to BOC.
Page 12
Step by step operating guidelines – INHALO ® Carry handle The carry handle has been ergonomically designed to provide a balanced and safe carry point for the INHALO ® device. The handle acts as a Cylinder fill port cover protection barrier for the gas outlets if and batch label.
Page 13
Details given in this document are believed to be correct at the time of printing. While proper care has been taken in the preparation, no liability for injury or damage resulting from its use can be accepted. BOC is a trading name of BOC BOC: Living healthcare Limited, a member of The Linde Group.
