Summary of Contents for Roving Networks RN-BTHID-RD-UM
- Page 1 RN -W IFLYCR -U M- .01 RN-BTHID-RD-UM Bluetooth HID Reference Design © 2012 Roving Networks. All rights reserved. USER MANUAL RN-BTHID-RD-UM-1.10 Version 1.10 5/21/2012 www.rovingnetworks.com...
- Page 2 The Bluetooth HID profile is typically used in applications such as keyboards, mice, and game controllers. To demonstrate the basic capability of the Bluetooth HID profile, Roving Networks has developed a Bluetooth reference design implemented in the RN-42 module. This document describes the reference design and how to use it.
-
Page 3: Operation
RN -BT H ID-RD -U M-1.10 You can also perform the following operations by pressing the buttons for a longer time: To put the controller to sleep, press B7 for 4 seconds. • • To toggle the iOS virtual keyboard, press B5 for 3 seconds. To toggle between modes 1 and 3, press B6 for 3 seconds. -
Page 4: Operational Modes
RN -BT H ID-RD -U M-1.10 Because the iRemote uses Secure, Simple Pairing (SSP), you do not need to enter a 4-digit pairing code. PC/Mac Pairing When you pair the iRemote with a PC or MAC that supports Bluetooth version 2.1 or greater, the iRemote uses SSP and you do not need to enter a 4-digit pairing code. -
Page 5: Advanced Features
For advanced users, the iRemote provides an additional serial port profile (SPP), allowing connection to the device for remote configuration or other purposes. For more information on SPP mode, refer to the Roving Networks Bluetooth advanced user guide, which is available on the Support page on the Roving Networks web site at http://www.rovingnetworks.com/Support_Overview. - Page 6 HID reports. NOTE: Header J4 is the programming header. If you are building your own board, Roving Networks recommends that you include a programming header so that you can load new firmware onto the Bluetooth device.
- Page 7 RN -BT H ID-RD -U M-1.10 Figure 2. Board Schematic www.rovingnetworks.com...
-
Page 8: Version History
Added ability to toggle iDevice virtual keyboard while B5 is pressed for 3 seconds Version 6.10 Initial Release • RESOURCES & RELATED DOCUMENTS For more information, refer to the following sources, which are available on the Support page on the Roving Networks website at http://www.rovingnetworks.com/Support_Overview. Bluetooth Advanced User Manual • •...
