Digiguard C-DG-PD2421POE User Manual

SONY 1080P HD‐IP CAMERA
C‐DG‐PD2421POE

Key Features:

∙
1/2.8" SONY 2.4MP High-resolution CMOS
∙
Mode 1080P(1920 X 1080)
∙
Onvif 2.4, WDR, 3D DNR, ICR, POE Built-In
∙
Main Stream: 1080P/720P@30fps
SPECIFICATION
DESCRIPTION
Imaging Device 1/2.8" SONY 2.43 Megapixel CMOS
Effective Pixels 1080P(1920 X 1080)
Video Compression
Synchronization Internal, Negative Sync
Brightness, contrast, saturation, sharpness
Image setting
can be adjusted
Onvif
S/N Ratio More than 50dB (AGC Off)
Min. Illumination 1.0Lux(Color),0.5Lux(BW)
IRIS Adjustment
LENS 2.8~12 Manual Zoom Lens
TCP/IP, HTTP, DHCP, FTP, DNS, DDNS, RTSP
Protocol
NTP、SMTP
IR LEDs
Gama Characteristic
IR Distance
Storage function FTP, Local, NVR, SMTP
Day&Night
Intelligent alarm Motion detection、Privacy
3D-DNR LEVEL(0~100)Adjustment
Digital Zoom
General function Single/Dual/Tri-Stream/Mirror
RJ45（10M/100M）Adaptive Ethernet port
Communication
Digital Effect OFF / V-FLIP / MIRROR / ROTATE
Digital Noise
WDR
Bit Rate
50Hz:25fps(1920×1080)
Frame Rate
60Hz:30fps(1920×1080)
Dimension (mm)
Weight(g)
Input Voltage
Power Consumption IR OFF : 210mA / IR ON : 550mA(±10%)
Operating Temp/Hum. -10ºC~ +50ºC / 30% ~ 80% RH
Storage Temp. / Hum. -20ºC ~ +60ºC / 20% ~ 90% RH
PAL
H.264/JPEG
Onvif 2.4
Auto
21Pcs LEDs
0.45
20 Meters
Auto
1.0X-8.0X
3D DNR
WDR
64-12000Kbps
￠135 x 100(H) mm
650
DC 12V(±10%)
WARRANTY
Product GIMBAL DOME CAMERA
Purchase
Address
Dealer
Please contact purchasing office or service center when you find any damage
▶
or problem with this product.
▶
The warranty period is 2 years from Invoice date.
◈A/S without cost◈
Within Warranty Period
When
damages
occurred in
Repair or Replace
nomal
working
environment
◈A/S with cost◈
Damage by customer's negligence
1. Damage by customer's careless handling
chargeabl 2. Damage by natural disaster (Fire, Flood, etc.)
e case 3. Damage by not keeping the cautions and instructions on manual
even 4. Damage by not using appointed power(frequency, voltage) or
within adapter.
warranty 5. Damage by disassemble or cleaning by customer
6. Damage by repairment by a person excepting the dealer
DIMENSION
Warranty Period: 2 years
Model
C-DG-PD2421POE
Serial No.
Customer
Representative
Warranty details
Within warranty After Warranty
Product
A/S without cost
Product
exchange
Warranty details
A/S with cost
