Trol Systems MCU-04-115 Installation Manual

Specifications for: MCU-04-115
Power Requirements:
115VAC @ .02A, 50/60Hz w/1000v magnetic isolation
Outputs:
4 normally open relay contacts unprotected, no leakage current
5Amps @ 230VAC ( resistive load ), 250 VA ( inductive load ).
Response time: 10ms operate / 5ms release
Rated life: 5 million ( mech ) / 200,000 @ 3A ( resistive load )
Inputs:
6 self powered, 12-14 VDC @ 10ma. w/ 1000v optical isolation.
Maximum leakage of input device: 0.5ma
Response time: all are factory set at 10ms, the user may change
any input to between 0 to 255ms using the Setup Menu.
Auxiliary Supply:
10 - 14vdc @ 100ma., thermal overload protected.
Physical:
Size 2.9" ( 75mm ) x 2.2" ( 55mm ) x 4.3" ( 110 mm )
Mounting DIN rail or panel ( with two #6 screws )
Weight 10 oz. ( 284 grams )
°
Temp 0 - 140 F, 90% r. humidity ( no condensation )
Origin Designed and assembled in the USA.
Communication Ports:
Expansion Twin RJ-11, IIc bus @ 100khz max.
PC Prog. 3.5mm, RS-232C @ 19200 Hi / 9600 Lo
Visit our web site at www.trolsystems.com for
latest information about the T6 control system.
T6 is a trade name of Trol Systems Inc.
TSI reserves the right to make changes to the information contained in this manual without notice.
publication MCU115- rev:5 | © 2003 TSI All rights reserved | printed in USA
T6 T6 T6 T6 T6
Installation guide for part number:
MCU-04-115
Main
Control
Unit
