Specifications for PWM Amplifier
Model: AMP-02
Operating Power Requirements
10 to 15vdc @ 10ma.
Output
Sinking configuration (NPN) HEXFET
+95 volts (absolute maximum), back emf protected
27 amps continuous (100% duty cycle)
85 amps intermittent (5% duty cycle)
28 micro second slew rate @ 15 amps
Input
1K ohm impedance, biased toward + supply
Threshold of comparator 50% of + supply .1v hysteresis
Physical
Size
2.9" (75mm) x .88" (22mm) x 4.3" (110 mm)
Mounting
DIN rail only
Weight
6 oz. (170 grams)
°
Temp
-20 to 140
Origin
Designed and assembled in the USA.
T6 & T6+ are trade names of Trol Systems Inc.
TSI reserves the right to make changes to the information contained in this manual without notice.
publication: AMP2 rev 2 | © 2000 TSI All rights reserved | printed in USA
F
Installation guide for part number:
AMP-02
PWM
Amplifier
Unit
Advertisement
Summary of Contents for Trol Systems AMP-02
- Page 1 Installation guide for part number: AMP-02 T6 & T6+ are trade names of Trol Systems Inc. TSI reserves the right to make changes to the information contained in this manual without notice. publication: AMP2 rev 2 | © 2000 TSI All rights reserved | printed in USA...
- Page 2 General: Wiring the input: This device is specifically designed to amplify the signal from an output of a Connect the output of the analog section that you want to amplify to the T6 analog I/O section. It takes the output signal and boosts its sinking capa- input of the amplifier.
