Lumascape PowerSync LS6550 Installation Instructions Manual

PowerSync™
LS6550
Low Voltage PowerSync™
Interface DIN Rail Mount
READ ALL SAFETY INSTRUCTIONS FIRST
› Follow instructions carefully, failure to do so could
damage equipment and will void warranty.
› Ensure installation complies with local law and
applicable standards.
› Input voltage is 30-48V DC maximum
› Only use Lumascape approved power supply, control
equipment and leader cables.
› Ensure mains input power is surge protected and power
filters are installed.
LUMASCAPE ASIA PACIFIC Brisbane Technology Park, 18 Brandl Street, Eight Mile Plains, QLD 4113, Australia
Phone +61 7 3854 5000 | Fax +61 7 3854 5001 | Email: sales@lumascape.com.au |
LUMASCAPE NORTH AMERICA 1300 Industrial Road, Unit #19, San Carlos, CA 94070, USA
Phone +1 650 595 5862 | Fax +1 650 595 5820 | Email: info@lumascape.com |
Products and specifications are subject to change without notice.
INSTALLATION INSTRUCTIONS
PS
LS6550
LOW VOLTAGE POWERSYNC
INTERFACE DIN RAIL MOUNT
› Never make or break connections whilst the circuit is
energised.
› Do not make modifications or alter the product.
› Keep electrical connections clean and free from
moisture.
› Ensure components are in an appropriate, dry and dust
free operating environment.
