- Page 1 UltraMini™ User Manual UltraMini™ Eternal Lighting User Manual 2018...
- Page 2 Introduction: Thank you for your purchase. The UltraMini™ is a 50 Watt LED Gobo Projector. Unpacking: Every UltraMini™ has been thoroughly tested and has been shipped in perfect operating condition. Carefully check the shipping carton for damage that may have occurred during shipping.
- Page 3 Gobo Size: 59mm Outside and 18mm Viewable image Overview Photographic chart Beam angle 19° Beam angle 26° 27440 2354 14440 1324 5444 1305 3025 Beam angle 36° Beam angle 50° 8815 4091 1832 UltraMini™ Eternal Lighting User Manual 2018...
-
Page 4: Installation
When the device put on horizontal place, the device must be placed directly in place, and devices must be secured with the mounting holder. When rigging the UltraMini™ on truss, insert the quick- lock fasteners of the first mounting holder into the respective holes on the bottom of the UltraMini™. Tighten the quick-lock fasteners fully clockwise. -
Page 5: Connection With The Mains
How to Insert the Powercord into the UltraMini™: CONNECTION WITH THE MAINS Pin 1 of power plug connects the "L'' of powercord, Pin 2 of power plug connects the "N" of powercord, Pin 3 of power plug connects the "GN" of the power-cord. - Page 6 The gobo Holder When you exchange the gobo, unscrew the Hjfosijosupport screw of the gobo holder, place gobo into the holder, then tighten the screw again. Put the gobo in the slot shown in the picture. UltraMini™ Eternal Lighting User Manual 2018...
- Page 7 Replace the fuseholder in the housing and fix it Unqualified people involved with installation, operation and maintenance of the UltraMini™ is prohibited. If any above mentioned problem happened, or unknown problem happened, please contact manufacture or distributor for assistance. For more information, please contact Support by email at support@eternallighting.com UltraMini™...
