Summary of Contents for JETBOX Blade
- Page 1 JETBOX Blade user manual...
- Page 2 1. DESCRIPTION The hand dryer is a surface-mounted hand dryer powered by a brush motor, and delivers 1650 watts of drying power. The dryer incorporates a replaceable HEPA filter and a reusable air intake prefilter. An infrared sensor is used to automatically activate the dryer. The dryer is intended for use in commercial, industrial, and office environments.
- Page 3 8. Set the Heater/Air Speed setting switches as required. 9. Replace the water collection tray. Power Switch 10. Open the pre-filter to install the HEPA filter if necessary with rubber ring side up. 11. Connect plug to power supply socket or turn on power. JETBOX Blade 3...
- Page 4 This warranty is only valid if the form card has been properly completed. For any warranty claim you should contact your supplier. Model: Serial No.: Distributor: Customer: Address: Tel No.: Fax No.: Date of purchase: For Seller: Signature : 4 JETBOX Blade...
- Page 5 Replace HEPA Filter and Clean Pre-filter WARNING: Disconnect power at the service breaker or unplug the hand dryer before servicing & maintenance. Soft rubber ring Pre air filter HEPA filter Hard plastic ring 1. Press back then down to remove the pre-filter. 2.
- Page 6 3. Gently remove the holder and the circuit board will come out. Take care of the adjoining wire. 4. Loosen the two screws on the circuit board and replace with the new one. 5. It is recommended to also replace the sticker. 6 JETBOX Blade...
- Page 7 . Remove the motor and replace it. 2. Replace motor housing. Ensure the motor protection rubber and air seal rubber fits correctly. 3. Replace Air Chamber cover. Ensure the air seal rubber is seated correctly to avoid air leakage. JETBOX Blade...
- Page 8 Hand Dryer by Brushless Motor Electric Diagram Hand Dryer by Brush Motor Electric Diagram Terminal blocks Power...
