Summary of Contents for Fass HK-1001
- Page 1 INSTALLATION MANUAL HK-1001 ACCESSORY: Electric Heater Kit FASS Series: HD, Titanium, or Platinum...
- Page 2 1. Read the installation manual completely before attempting installation. The instal- lation of this product indicates that the buyer has read and understands the limita- tions of the FASS manufacturers warranty agreement and accepts the responsibility of its terms and conditions.
- Page 3 Contents WH-1006 HE-1001 Ring Terminal HB-1001 Fuse Tap Flag Terminal 10-260 FASS Series Instruction Page 5 - 6 8 - 10 8 - 10...
- Page 4 These instructions are for the application to a FASS HD Series system. Note: Installation can be performed without removing system from truck. a. Remove brass plug directly above the water separator. b. Apply thread tape to provided bushing and install. Torque to 40 ft./lbs.
- Page 5 a. Connect male end of harness to the heating element. Route the wire harness to the battery. Use wire ties to secure harness. b. Route the single red wire coming off the relay through a grommet in the fire wall. c.
- Page 6 Turn key to the accessory position. Allow heater to warm for 10-15 minutes. After warm-up, start engine as normal. Note: Heater element has automatic on/off temperature control as long as power is applied. Two heater elements can be installed simultaneously. Use the directions in the kit to install in both ports. Use both harnesses and join the leads at the terminals.
- Page 7 Platinum Series Titanium Series a. Remove brass plug directly above the water sepa- rator. b. Apply thread tape to the HB-1001 Heater Bushing and install. Torque to 40 ft./lbs. c. Apply thread tape to heater element. Insert into bushing. Torque to 18 ft./lbs. a.
- Page 8 a. Connect male end of harness to the heating element. Route the wire harness to the battery. Use wire ties to secure harness. b. Route the single red wire coming off the relay through a grommet in the fire wall. c.
- Page 9 Turn key to the accessory position. Allow heater to warm for 10-15 minutes. After warm-up, start engine as normal. Note: Heater element has automatic on/off temperature control as long as power is applied. Two heater elements can be installed simultaneously. Use the directions in the kit to install in both ports. Use both harnesses and join the leads at the terminals.
