NOMASENSE O
P300 & P6000
2
USER GUIDE
WW W.VI NV EN T I O NS. CO M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NOMASENSE O2 P300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Wine Quality Solutions NOMASENSE O2 P300

  • Page 1 NOMASENSE O P300 & P6000 USER GUIDE WW W.VI NV EN T I O NS. CO M...
  • Page 2 P300 & P6000 CONTENT • NomaSense or O P300 or P6000 oxygen analyzer • USB cable • USB-Power adapter (5 VDC, min. 1 A) with different connector pieces • USB stick including the Datamanager Software • Temperature probe PT100 • Short optical fiber Fig.

  • Page 3: Description Of The Device

    P300 & P6000 DESCRIPTION OF THE DEVICE TOP PANEL The top panel is equipped with a connector for the fiber optic sensor, a connector for the temperature sensor, and the QR code reader. TEMP Fig. 2 Transmitter top panel BOTTOM PANEL The bottom panel is equipped with the USB connector for charging the battery or connecting BATT...

  • Page 4: Getting Started

    P300 & P6000 GETTING STARTED 1. INSTALLATION – SET-UP • Remove the red rubber cap from the optical sensor connector (SMA) • Remove the protective cap from the male plug on the optical fiber and insert it in the SMA connector of the NomaSense P300/P6000.
  • Page 5 P300 & P6000 4. CREATE A NEW SENSOR MANUALLY: • Use the button to switch to the Main menu. • Select “Sensors” and press the button to edit the sensor list. A window appears; select New Sensor and press • Select Manual and press •...
  • Page 6 P300 & P6000 • To save measurements select Logging On and go to Measurement Browser. Use the button to create a new measurement file. A keyboard screen opens. Use the navigation arrows to type in the new Measurement Name. • When you have finished typing go to the Done button and press •...
  • Page 7 P300 & P6000 • Open the Datamanager software after installation and select a working directory in which your P300 / P6000 data is going to be stored. • The connected device shows automatically in the software; go to the Measurements tab on top. •...

  • Page 8: Menu Structure

    P300 & P6000 MENU STRUCTURE Main Measurement Simple Oxygen ➔ ➔ Temperature ➔ Details Oxygen (+ phase angle, ➔ ➔ amplitude) Temperature ➔ Measurement Name ➔ General (measurement settings) ➔ Graph ➔ Settings Temperature Auto ➔ ➔ Manual ➔ Pressure Auto ➔...
  • Page 9 P300 & P6000 MENU STRUCTURE Main Sensors Sensor list Select ➔ ➔ Edit List Delete Sensor ➔ ➔ New Sensor Barcode ➔ ➔ Manual Sensor Settings Sensortype ➔ ➔ ➔ Sensor ➔ Constants Calibration Dry / Humid ➔ ➔ Data Cal0 T0 ➔...
  • Page 10 NOMASENSE O P300 & P6000 CONTACT US FOR YOUR CUSTOMIZED SOLUTION Vinventions LLC | 400 Vintage Park Dr. | Zebulon, NC 27597 | U.S.A. | Tel : +1 919-460-2200 | vinventions.com Vinventions | ZI Les Plénesses | Chemin de Xhénorie 7 | B-4890 Thimister-Clermont | Belgium | Tel : +32 87 63 88 20 winequalitysolutions@vinventions.com WW W.VI NV EN T I O NS.
