INDUSTRIAL - AQUEOUS PARTS CLEANER
I. Introduction
A. Manufacturer's Statement
This manual will provide you with important information about the Aqueous Parts Cleaners and will
instruct you on how to use this equipment in a safe manner.
The information contained in this manual is necessary for the safe, proper setup and operation of
your Aqueous Parts Cleaner.
Keep this manual, along with the Material Safety Data Sheets (MSDS) for the solution in use, within
easy reach of the operator of this parts cleaner.
The equipment described in this manual is subject to change. The manufacturer reserves the right to
change equipment at any time as part of normal product improvement. Some improvements may
have been made after this manual was printed. For the latest information on your equipment, contact
the manufacturer.
B. General Information
The Industrial Aqueous Parts Cleaner is an economical, safe, and innovative system designed to
clean parts, using an aqueous based solution. Aqueous solutions, when used to clean grease and oil,
must be disposed of properly. Consult your local environmental management agency for additional
guidance and other potentially hazardous materials compliance requirements.
Install your parts cleaner on a flat, level surface in an area provided with adequate ventilation. Avoid
repeated or prolonged breathing of vapors. Do NOT use compressed air to dry parts as this may
cause a high concentration of vapors in the immediate area. Local exhaust ventilation should be used
in areas of high vapor concentration. Provisions for determining and maintaining adequate ventilation
are the responsibility of the operator.
Make sure the parts cleaner is connected to a properly grounded power source. Check serial plate for
power requirements.
Do NOT allow the parts cleaner to operate unattended.
04385
REV E
OPERATION & INSTRUCTION MANUAL
READ AND UNDERSTAND ALL LABELS, MSDS, AND
THIS INSTRUCTION MANUAL BEFORE USE.
EM5000
CAUTION
Page 1
02/09/2016
Advertisement
Table of Contents
Summary of Contents for Fountain EM5000
- Page 1 INDUSTRIAL - AQUEOUS PARTS CLEANER OPERATION & INSTRUCTION MANUAL EM5000 I. Introduction A. Manufacturer’s Statement This manual will provide you with important information about the Aqueous Parts Cleaners and will instruct you on how to use this equipment in a safe manner.
-
Page 2: Safety Instructions And Information
II. Safety Instructions and Information Complete safety in use is dependent upon proper use and handling of the parts cleaner in your workplace. It is important that you follow the instructions provided in this manual. If you fail to read, understand, and follow all of the procedures in this manual, you may cause or suffer personal i njury. -
Page 3: Important Safety Instructions
A. Important Safety Instructions 1. Read all instructions. 2. Care must be taken as burns can occur from touching hot parts. 3. Do not operate equipment with a damaged cord or if the equipment has been dropped or damaged – until it has been examined by a qualified service person. 4. -
Page 4: In Case Of Fire
B. Service Call your representative should your parts cleaner need service and always unplug unit when servicing. Inspect and keep in good working order the power cord and all electrical components. If components show signs of damage or wear replace immediately. All work should be done by a trained technician. Do NOT replace pump before unplugging unit and letting it completely cool down. -
Page 5: Installation
4. INGESTION (Swallowing): (Uncontaminated cleaning solution) Drink 4 to 8 ounces of water and seek medical attention. DO NOT induce vomiting. E. Environmental 1. Avoid spilling solution. Spilled solution can create slippery conditions, clean it up immediately. Close off area to traffic. Wear appropriate personal protective equipment to prevent eye and skin contact. -
Page 6: Operation
For units with Bio Pump, plug the power cord into a properly grounded power source. Power Requirements = 15 amp, 115 volt, 60 Hz IV. Operation This unit has an automatic low-fluid control sensor. Unit operates on 30-35 gallons (113.6-132.5 L.) or more of fluid. -
Page 7: Wiring Diagram
VALVE ............................13-10164-02 FILTER, STRAINER ........................8135 STRAINER, GRATE METAL......................8136 FILTER MOUNT ..........................04826 FILTER ADAPTER..........................62002 FILTER, 50MIC CANISTER ......................MLF4850 FUSIBLE LINK ..........................01178 DOOR CLOSURE...........................02-10698-250 KNOB, THREADED……………………………………………………………………………………….15-10238 WASHER…………………………………………………………………………………………………...30038 KNOB, THUMB…………………………………………………………………………………………….15-10249 COUPLER, CAM…………………………………………………………………………………………..16-10204 COUPLER, CAM MALE…………………………………………………………………………………..16-10203 CONTROL MODULE COMPLETE………………………………………………………………………61337-01 SWITCH ROCKER .........................62262 THERMOSTAT ..........................12-10149 TOGGLE SWITCH..........................12-10147 POWER CORD..........................05083 HEATER ............................12-10208... -
Page 8: Control Module
CONTROL MODULE 04385 Page 8 02/09/2016 REV E... -
Page 9: Troubleshooting
VII. TROUBLESHOOTING Machine does not operate: 1. Make sure the parts cleaner is connected to electric power or air supply. 2. Check for incoming power. Check serial plate for power requirements. 3. On electric units: check reset button on GFCI cord to make sure it is not tripped. On air units: an increase in air supply may be required. - Page 10 Fountain’s approved solutions or accessories. If any Equipment fails to conform to the specifications or samples or any defect in material or manufacture appears within twelve (12) months from the date of initial purchase by end user Fountain’s entire liability, and Customer's or end user’s exclusive remedy, shall be, to either repair or replace such defective Equipment, at Fountain’s option, within a...
