Mark-10 BGI User Manual

Digital force/torque indicator

Advertisement

Model BGI
DIGITAL FORCE / TORQUE INDICATOR
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BGI and is the answer not in the manual?

Questions and answers

Summary of Contents for Mark-10 BGI

  • Page 1 Model BGI DIGITAL FORCE / TORQUE INDICATOR User’s Guide...
  • Page 2: Table Of Contents

    Series BGI Thank you! Thank you for purchasing a Mark-10 Series BGI Digital Force Gauge. We are confident that you will get many years of great service from this product. Mark-10 digital force gauges are designed to be easy to use and ruggedly constructed for many years of service in laboratory and industrial environments.
  • Page 3: Controls - Section 1

    User’s Guide CONTROLS Six keys on the front panel are used for all functions and control of the instrument. Some have more than one function, depending on the mode of operation. The main functions are labeled above the keys and the secondary functions are below the keys in smaller type.
  • Page 4: Configuration - Section 3

    This prevents the instrument from working at voltages too low for reliable operation. CONFIGURATION The BGI indicator has several features with programmable options allowing many user-specified choices. In order to access the configuration menu, perform the following: 1.
  • Page 5 User’s Guide 232 - RS-232 settings 232d Output Disabled 232E Output Enabled 300 baud 600 baud 1200 1200 baud 2400 2400 baud 4800 4800 baud 9600 9600 baud 7-1E 7 data bits, 1 stop bit, even parity 7-1o 7 data bits, 1 stop bit, odd parity 7-2E 7 data bits, 2 stop bits, even parity 7-2o...
  • Page 6: Filters - Section 4

    By varying the length of the buffer, a variable smoothing effect can be achieved. The BGI is equipped with a buffer which can hold up to eight readings. The number of readings to be averaged can be set to 1,2,4 or 8.
  • Page 7: External Trigger Mode - Section 5

    User’s Guide The analog and the digital filters should be disabled or set to their minimum acceptable values for highest peak capture speed. EXTERNAL TRIGGER MODE This mode of operation is useful for measuring electrical contact activation force as well as synchronization of multiple instruments for a "snap-shot" view of the applied force or torque.
  • Page 8: Average Mode - Section 7

    Series BGI and repeat the above steps for the low set point. After entering both values, "donE" will appear on the display. Press ENTER to store the changes or ESCAPE to quit. In either case "SP" will appear on the display and the ENTER key may be used for re-entering the set point change mode or the MODE key for proceeding with the normal operation of the gauge.
  • Page 9 User’s Guide Switch units to pounds Switch units to kilograms Switch units to Newtons Switch units to grams OZIN Switch units to ounce-inches LBIN Switch units to pound-inches KGMM Switch units to kilogram-millimeters Switch units to newton-centimetes Switch units to newton-meters Enable External trigger mode Disable External trigger mode Edge triggered External trigger mode...
  • Page 10: Outputs - Section 9

    Series BGI Print/send data to a Mitutoyo compatible device Set output bit (open collector, pull to ground). n=0,1,2 Clear output bit. n=0,1,2 Read current status of output bit or level of input pin. n=0,1,2,3 SAVE Save current settings in nonvolatile memory Enter Calibration mode.
  • Page 11: Mitutoyo Bcd

    User’s Guide 9 OUTPUTS RS-232 The data transmission can be initiated by pressing the DATA key or by an external device by sending ASCII "?" to the gauge. The indicator will respond by sending the current reading in either full or numeric format, depending on the configuration settings (see Section 3).
  • Page 12: I/O Connector Pin Diagram

    Series BGI I/O connector pin diagram RS-232 receive Input RS-232 transmit Output Mitutoyo request Input External trigger " Input bit 3 " Mitutoyo clock Output "Within" set point output " Output bit 2 " Signal ground +Analog signal Output +12V DC...
  • Page 13: Dimensions

    I/O CONNECTOR WARRANTY Mark-10 Corporation expressly warrants to its buyer for one year from the date of delivery that the goods sold are free from defects in workmanship and materials. Mark-10 Corporation will, at its option, repair or replace or refund the purchased price of goods found to be defective.
  • Page 14 Mark-10 Corporation has been an innovator in the Force and Torque measurement fields since 1979. We strive to achieve 100% customer satisfaction through excellence in product design, manufacturing and customer support. In addition to our standard line of products we can provide modifications and custom designs for OEM applications.
