Wiring Diagrams; Replacement Parts List - Coffing Hoists EMW Series Operating, Maintenance & Parts Manual

Parts List for EMW Exploded View
Ref Description
No.
1 Suspension Frame
2 Control Cover
3 Transmission Cover
4 Drum
5 Bottom Block Frame
6 Sheave
7 High Speed Pinion
8 High Speed Cluster Gear
9 Intermediate Cluster Gear
10 Intermediate Gear
11 Output Pinion
12 Output Gear
13 Thrust Washer
14 Thrust Washer
15 Drum Shaft
16 Drive Coupling
17 Cable Assembly, 20 ft.
18 Hook Assembly
(Includes Ref. No. 20)
19 Hook Assembly
(Includes Ref. No. 20)
20 Latch Kit
21 Hook Collar
22 Pushbutton Station Assembly
(Includes Ref. Nos. 23-29)
23 Warning Label
24 Pushbutton Enclosure
25 Pushbutton Enclosure
26 Rocker Switch
27 Pushbutton Cord Assembly
28 Pushbutton Screw
29 Pushbutton Flexloc Nut
30 Power Cord Assembly
31 Motor
32 Cable Guide
33 Insulator
34 Switch (Limit Switch)
Figure 3 — 981MH4 Wiring Diagram
For more information contact: Sievert Crane and Hoist, (708) 771-1600, parts@sievertelectric.com, www.sievertcrane.com
Part Qty Ref
No. No.
33K4-5 1 35
36K9-2 1 36
35K4 1 37
16K4 1 38
30K4 2 39
28K4 1 40
400K8 1 41
406K1 1 42
406K2 1 43
403K10 1 44
404K6 1 45
405K5 1 46
255K1 6 47
255K2 4 48
132KG6 1 49
107K27 1 50
19K301 1 51
3M002C01S 1 52
53
3M102C01S 1 54
55
4X1302 2 56
124K2 1 57
MH534-1 1 58
59
687K3W 1 60
MH48R 1 61
MH48L 1 62
4K1 1 63
936KG9 1 64
H2967 2 65
H3972 2 66
951KG2 1 67
861K350A 1 68
210K4 1 69
759K1 1 70
815K5 1
7
Description
Paddle (Limit Switch)
Capacitor
Retaining Ring
Bearing
Load Bearing
Woodruff Key (Drum)
Woodruff Key (Output Gear)
Screw
Lockwasher
Bottom Block Screw
Dowel Pin
Hook Pin
Plug
Dowel Pin
Setscrew
Screw
Washer
Screw
Splice Connector
Gasket
Warning Label
Capacity Label
Coffing Label
Nameplate
Cotter Pin
Woodruff Key
Oil Seal
Motor Brake Assembly
Brake Cover
Screw
Screw
Rectifier
Wire Channel
Pipe Plug
Brake Harness
Lubricant
Part Qty
No.
24K5B 1
810K1A 1
H5543 2
521K3 8
521K4 2
H4355 1
H4356 1
H1841P 6
H4061P 6
H2743P 2
H5387 1
H5159 1
H6292 1
H5383 2
S7-121 1
H2742P 1
H4004P 1
H2744P 2
H5757 3
MH560 1
MH687 1
MH675-2 2
912500001 2
MH674-10 1
H5021P 1
H4362 1
561K29 1
MH854T 1
36K206 1
H1303 2
H2752 1
840J1 1
MH270 1
S25-13 1
940J11 1
H7653 / lb.
