Summary of Contents for Connective Touch SmartPro
- Page 1 USER GUIDELINES Connective Touch FINGERPRINT READERS ACCESS CONTROL SYSTEM SmartPro user manual ConnectiveTouch.com...
-
Page 2: Table Of Contents
ENROLMENT PROCESS ............6 TIPS FOR BEST FINGERPRINT ENROLMENT ........6 Net2 Setup Considerations ............7 New User Enrolment ..............8 New Fingerprint Enrolment (User Token Details) ....... 13 Deleting FingerPrint templates (User Token Details) ......17 SMARTPRO USER MANUAL AG|0510|DS|04|16... -
Page 3: Getting Started
This User Guide details the key functionalities for: - Fingerprint Enrolment Software for Users on ‘Net2 Access Control’ - The management of Users within ‘Net2 Access Control’ - The management of access to SmartPro Biometric Access Control units SMARTPRO USER MANUAL AG|0510|DS|04|16... -
Page 4: Glossary Of Terms / Abbreviations
Software from Paxton used in conjunction with the Paxton ACU (Access Control Unit). Net2 Pro /Plus/Lite / Client Install versions of Net2 Access Control Net2 Server Paxton supplied administration software Paxton Net2 v5.03 Supplied administration software SMARTPRO USER MANUAL AG|0510|DS|04|16... - Page 5 Within Net2 the FingerPrint Templates are referred to as Tokens Within ‘Fingerprint Admin’ (installed as Zone ID FPRegister) the terms Zone and Zone ID are used to determine a number of doors or access points registered within a group SMARTPRO USER MANUAL AG|0510|DS|04|16...
-
Page 6: Important Safeguards
Clean sensor occasionally with dry or anti-bacterial wipes to maintain the performance of the sensor. Figure 1. SmartPro FP Verification Unit SMARTPRO USER MANUAL AG|0510|DS|04|16... -
Page 7: Enrolment Process
ENROLMENT PROCESS The Enrolment Unit is provided to enrol approved personnel into the SmartPro system. The level permissions of each user are saved in the Main Administrator PC. TIPS FOR BEST FINGERPRINT ENROLMENT WHAT YOU SHOULD DO Place finger flat on the fingerprint sensor. -
Page 8: Net2 Setup Considerations
‘Net2 operators’ – who has permission to access ‘Net2 Access Control’ and the functionality they require as: ‘New operator’ ‘OEM Client’ ‘System engineer’ These are all covered in the ‘SmartPro Software Installation Guide’ SMARTPRO USER MANUAL AG|0510|DS|04|16... -
Page 9: New User Enrolment
User is to create the User in ‘Net2 Access Control’: Log into ‘Net2 Access Control’ using the User name and Password provided. Figure 4. Net2 Software A screen similar to the one below will appear after a successful log in. Figure 5. Net2 Software SMARTPRO USER MANUAL AG|0510|DS|04|16... - Page 10 4. Click on ‘New user’ in the upper toolbar 5. the ‘Add user’ screen shown below will appear. minimum details that need to be entered are: First name Surname Token type Access level Figure 7. Net2 - Add User SMARTPRO USER MANUAL AG|0510|DS|04|16...
- Page 11 ‘Events’ occur, all the details can be viewed Figure 8. Net2 - User Details - Access Right After the User has been created in ‘Net2 Access Control’ the User’s Fingerprint has to be registered/enrolled by using the ConnectiveTouch FP Enrolment software. SMARTPRO USER MANUAL AG|0510|DS|04|16...
- Page 12 Start and Log in to the ‘Fingerprint Admin’ software using the login and password provided. Figure 9. CT Fingerprint Registration Software Log in The screen shown below will appear. Ensure you are on the ‘Fingerprints’ Tab and click ‘Search’ Figure 10. CT Fingerprint Registration Software - Search SMARTPRO USER MANUAL AG|0510|DS|04|16...
- Page 13 NOTE: If NO Users appear (and there are some on Net2) ‘Net2 Access Control’ MUST be closed and restarted (the Administrative tools / Services only shows the Service was started and NOT that it is now not working!) SMARTPRO USER MANUAL AG|0510|DS|04|16...
-
Page 14: New Fingerprint Enrolment (User Token Details)
Figure 12. CT FP Registration Software - Fingerprint Registration Place the selected finger on the ‘Enrolment unit’ and click ‘Start’ While registering/enrolling the dots will be circling Good Registration of a fingerprint will take about 7 seconds. Figure 13. FP Registration SMARTPRO USER MANUAL AG|0510|DS|04|16... - Page 15 ‘Token’ will appear. Figure 14. FP Accepted Fingerprint template / token. Figure 15. Net2 - User Details – Tokens Only one numbered Token will appear for a User even if two fingers have been enrolled. SMARTPRO USER MANUAL AG|0510|DS|04|16...
- Page 16 Once successfully registered / enrolled, details of the FP template will be stored in ‘NET2 Access Control’ as a ‘Token’ number and in all SmartPro readers (as TPL/DAT files). The ‘Token’ type can be changed from ‘Unspecified’ (the Key) to ‘Fingerprint verification card’...
- Page 17 - try again Once the FPs are registered, all User events are logged in ‘Net2 Access Control’. This will build into a history of events for both the ‘User’ and the ‘Doors’ SMARTPRO USER MANUAL AG|0510|DS|04|16...
-
Page 18: Deleting Fingerprint Templates (User Token Details)
‘Search’ button as shown below a list of all the Users will be displayed. Click ‘Delete’ against Fingerprint that needs to be deleted. Figure 18. CT Fingerprint Registration Software - Users List SMARTPRO USER MANUAL AG|0510|DS|04|16... - Page 19 Once Deleted, the below screen will appear with no green tick against the User name and Fingerprint 1 or 2 and the details will be logged in ‘Net2 Access Control’ ‘Events’ for that User. Figure 20. CT Fingerprint Registration Software - Users List SMARTPRO USER MANUAL AG|0510|DS|04|16...
- Page 20 Connective Touch has a national help desk, manned by the people that designed and developed Connective Touch, ensuring that all end users can fully understand the potential of their product and how to maximise the benefits, safe in the knowledge they can trust the support and advice they receive.
