QM, QA & QC CONTROLLER
QM CONTROLLER
IMPORTANT - INSTALLER MUST COMPLETE FOR WARRANTY PURPOSES
Model:
Installation Date:
Dealer:
OWNER'S MANUAL:
QA CONTROLLER
Serial Number:
Installed by:
Invoice No:
QC Series
QC CONTROLLER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QM and is the answer not in the manual?

Questions and answers

Summary of Contents for Airgroup QM

  • Page 1 OWNER’S MANUAL: QM, QA & QC CONTROLLER QC Series QM CONTROLLER QA CONTROLLER QC CONTROLLER IMPORTANT - INSTALLER MUST COMPLETE FOR WARRANTY PURPOSES Model: Serial Number: Installation Date: Installed by: Dealer: Invoice No:...

  • Page 2: Table Of Contents

    CONTENTS MAXIMISING YOUR COOLBREEZE EVAPORATIVE AIR CONDITIONER QUICK START GUIDE: ALL CONTROLLERS QM CONTROLLER INSTRUCTIONS QA AUTO CONTROLLER INSTRUCTIONS QC AUTO CONTROLLER INSTRUCTIONS QC AUTO CONTROLLER TEMPERATURE CALIBRATION SETTING UP COOLBREEZE CONNECT GENERAL INFORMATION: APPLICABLE TO ALL CONTROLLERS GENERAL INFORMATION & MAINTENANCE...

  • Page 3: Maximising Your Coolbreeze Evaporative Air Conditioner

    MAXIMISING YOUR COOLBREEZE EVAPORATIVE AIR CONDITIONER CoolBreeze evaporative air-conditioning provides a continuous supply of cool, fresh, filtered air into your home to push out the warm, stale air. To maximise the cooling efficiency it is important to allow sufficient window or door openings to disperse the warm, stale air. Ceiling outlets should be positioned across the room from the window to allow the cool air to pass through the room and exit through the window.

  • Page 4: Quick Start Guide: All Controllers

    To bypass the pre-start wash, press ‘Fan’, then ‘Cool’. Adjust speed as follows: ▲ ▼ Use the buttons. Turn the unit off by pressing the ‘Off’ button WI-FI (QC ONLY) COOL COOL TIMER EXHAUST AUTO EXHAUST DOWN DOWN QM CONTROLLER QA/QC AUTO CONTROLLER...

  • Page 5: Qm Controller Instructions

    QM CONTROLLER INSTRUCTIONS MAIN CONTROLS Switches the unit off. When the air conditioning system is switched off, the water tank is emptied and a fresh tank of water is taken in. The fresh water is used to perform a 15 minute FLUSH cycle.
  • Page 6 WATER MANAGER SYSTEM SETTINGS The Water Manager System has been factory set at 5 hours. The DRAIN, WASH and FLUSH cycles can be adjusted using the DIP switches on the Keypad circuit board. (Service Technician only to adjust) They function as follows: DRAIN CYCLE INTERVAL: 5 hour drain cycle interval - DIP switch 1 to OFF position –...

  • Page 7: Qa Auto Controller Instructions

    QA AUTO CONTROLLER INSTRUCTIONS MAIN CONTROLS COOL TIMER AUTO EXHAUST DOWN QA AUTO CONTROLLER Function Screen View Description C 50 COOL In COOL mode, both the fan and water pump operate to provide cool airflow throughout the property. Airflow can be adjusted from 1% to 100% using the UP and DOWN buttons.
  • Page 8 The EXHAUST function allows the hot air which has built up to EXHAUST be expelled before the cooling process starts, this can reduce the time needed to cool the property. If the unit is operating in COOL or FAN mode when switched to EXHAUST, there will be a 30 second delay to allow the motor to stop prior to reversing direction.
  • Page 9 SAFETY (BUSHFIRE) MODE The SAFETY mode allows the water pump to continue to operate to keep the filter media wet while the fan is switched off to prevent smoke being drawn into the property. To operate this mode do as follows” •...

  • Page 10: Qc Auto Controller Instructions

    QC AUTO CONTROLLER INSTRUCTIONS MAIN CONTROLS Indicates WIFI connection COOL TIMER AUTO EXHAUST DOWN Reset button (see pg 14) QC Series C 50 Function Screen View Description In COOL mode, both the fan and water pump operate to provide COOL cool airflow throughout the property.
  • Page 11 The EXHAUST function allows the hot air which has built up to EXHAUST be expelled before the cooling process starts, this can reduce the time needed to cool the property. If the unit is operating in COOL or FAN mode when switched to EXHAUST, there will be a 30 second delay to allow the motor to stop prior to reversing direction.
  • Page 12 SAFETY (BUSHFIRE) MODE The SAFETY mode allows the water pump to continue to operate to keep the filter media wet while the fan is switched off to prevent smoke being drawn into the property. To operate this mode do as follows” •...
  • Page 13 QC CONTROLLER SETTINGS MODE – FACTORY SETTING The right hand column figures can be adjusted Once you have made your selected adjustment Press OFF to exit the settings menu Settings Ref Setting Name Screen View Setting Value S-1 5 Pre-Wash Cycle Minutes S-2 1 Drain After Pre-Wash...

  • Page 14: Qc Auto Controller Temperature Calibration

    ADJUSTING TEMPERATURE CALIBRATION ON A QC CONTROLLER Indicates WiFi connection To calibrate the temperature the keypad must be in standby mode with the ambient temperature displaying. • Press and continue to hold the OFF button • Press and continue to hold the TIMER button •...

  • Page 15: Setting Up Coolbreeze Connect

    SETTING UP COOLBREEZE CONNECT Indicates WiFi connection * Reset Button QC Series To set up CoolBreeze Connect, you will need your QC Controller, your home Wi-Fi details (name and password) and a Wi-Fi-enabled device (a laptop, smartphone or tablet). Visit www.connect.coolbreeze.com.au, or download the CoolBreeze Connect App from the Apple App Store or Google Play Store.

  • Page 16: General Information: Applicable To All Controllers

    GENERAL INFORMATION: APPLICABLE TO ALL CONTROLLERS • If the unit appears to surge at times, check that strong wind drafts are not the cause. A strong gust of wind may cause the fan to race momentarily as it is ‘wind assisted’. •...
  • Page 17 9. Adjust the water level if necessary. Ideally this level should be 10mm below the overflow. 10. Check that the water is being evenly distributed over the pads and that there are no obstructions in the water distributor, located above the pads. 11.

  • Page 18: Troubleshooting Guide

    TROUBLESHOOTING GUIDE Fault Action No display on Control Panel Check circuit breaker or fuse in meter-box If circuit breaker and fuses are ON, call for service Fan operating but blowing warm air Check that Control Panel is set to Cool or Auto Cool Turn unit off and see if water runs from drain pipe (wait 5- 10 minutes to drain) NO - Check the water supply tap is turned on YES –...

  • Page 19: Coolbreeze Product Warranty Terms And Conditions

    AUSTRALIA ONLY FOR MODELS PURCHASED FROM 01 OCTOBER 2016 This AirGroup Australia (the Manufacturer) Warranty is provided in addition to and in conjunction with the statutory warranties contained in the Australian Consumer Law and provided to you as the Purchaser (the Consumer) of an AirGroup Australia product (the Product).
  • Page 20 10. Changes in appearance to the Product or components, unless they have a significant effect on unit function. PLACE OF SERVICE For products installed further than 25 km from an AirGroup Australia Designated Service Agent (DSA), a supply part only warranty applies from the Manufacturers warehouse (Perth or Melbourne). Diagnosis of the required part/s needs to be done by a suitably qualified person, before any parts will be supplied.
  • Page 21 CoolBreeze air conditioner product. 2. That within the fifth year from purchase, an Extension Service is carried out by AirGroup Australia or their designated service agent. 3. This Warranty Extension Service will be charged to the Purchaser by AirGroup Australia. The service will be carried out by an AirGroup Australia designated service agent.
