Summary of Contents for Hills PAC-17LED-P
- Page 1 TFT-LED MONITOR PAC-17LED-P(Rev.A) PAC-19LED-P(Rev.A) User’s Manual Please read this manual thoroughly before use, and keep it handy for future reference.
-
Page 3: Table Of Contents
INSTRUCTION MANUAL ··············· 01 CONTENTS SAFETY INSTRUCTION ..................CAUTIONS ......................FCC RF INTERFERENCE STATEMENT ............... CONNECTING WITH EXTERNAL EQUIPMENT ........... REMOTE FUNCTIONS ..................CONTROLS AND FUNCTIONS ................8~15 MOUNTING GUIDE ....................D-SUB CONNECTOR PIN ASSIGNMENTS ............POWER MANAGEMENT ..................SPECIFICATIONS....................TROUBLE SHOOTING GUIDE ................ -
Page 4: Safety Instruction
02 ··············· INSTRUCTION MANUAL SAFETY INSTRUCTION Important Safety Instruction 1. Read these instructions. 2. Keep these Instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. - Page 5 INSTRUCTION MANUAL ··············· 03 SAFETY INSTRUCTION - The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed no the apparatus. - Minimum distances(e.g. 10cm) around the apparatus for sufficient ventilation. “...
-
Page 6: Cautions
04 ··············· INSTRUCTION MANUAL CAUTIONS ► CAUTION The power supply cord is used as the main disconnect device, ensure that the socket-outlet is located/installed near the equipment and is easily accessible. ► ATTENTIONN Le cordon d`alimentation est utillsé comme interrupteur général. La prise de courant doit être située ou installée à... -
Page 7: Fcc Rf Interference Statement
INSTRUCTION MANUAL ··············· 05 FCC RF INTERFERENCE STATEMENT NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 8: Connecting With External Equipment
06 ··············· INSTRUCTION MANUAL CONNECTING WITH EXTERNAL EQUIPMENT A. BOTTOM PANEL CONTROL 1. DC 12V IN 2. HDMI IN 3. VGA(D-SUB) IN 4. AV1 IN 5. AV2 IN 6. AV1 and AV2 OUT 7. PC AUDIO IN... -
Page 9: Remote Functions
INSTRUCTION MANUAL ··············· 07 REMOTE FUNCTIONS B. REMOTE CONTROLLER (Option) 1. POWER ( ) : Press once to switch on your tv set and again to enter the stand-by state 2. MUTE ( ) : Press once to mute the speakers and again to resume the sound. -
Page 10: Controls And Functions
08 ··············· INSTRUCTION MANUAL CONTROL AND FUNCTIONS C. FRONT KEY CONTROL The power supply cord is used as the main disconnect device, ensure that the socket-outlet is located/installed near the equipment and is easily accessible. 1. SOURCE / Select input source, and move the previous menu. 2. - Page 11 INSTRUCTION MANUAL ··············· 09 CONTROL AND FUNCTIONS ► Picture Menu Description All picture, sound settings and setup for the monitor can be adjusted in the OSD menu. (On Screen Display) To adjust the OSD screen: 1. Press the Menu button to enter the OSD menu. 2.
- Page 12 10 ··············· INSTRUCTION MANUAL CONTROL AND FUNCTIONS 1) COLOR TEMP Cool Gives the white color a bluish tint. Normal Gives the white color a neutral tint. Warm Gives the white color a reddish tint. 2) SCALE Center Sets the image size to Center Normal Sets the image to normal 3) PICTURE MODE...
- Page 13 INSTRUCTION MANUAL ··············· 11 CONTROL AND FUNCTIONS ► Sound Menu Description All picture, sound settings and setup for the monitor can be adjusted in the OSD menu. (On Screen Display) To adjust the OSD screen: 1. Press the Menu button to enter the OSD menu. 2.
- Page 14 12 ··············· INSTRUCTION MANUAL CONTROL AND FUNCTIONS ► OSD Menu Description All picture, sound settings and setup for the monitor can be adjusted in the OSD menu. (On Screen Display) To adjust the OSD screen: 1. Press the Menu button to enter the OSD menu. 2.
- Page 15 INSTRUCTION MANUAL ··············· 13 CONTROL AND FUNCTIONS ► Advance Menu Description All picture, sound settings and setup for the monitor can be adjusted in the OSD menu. (On Screen Display) To adjust the OSD screen: 1. Press the Menu button to enter the OSD menu. 2.
- Page 16 14 ··············· INSTRUCTION MANUAL CONTROL AND FUNCTIONS ► Geometry Menu Description All picture, sound settings and setup for the monitor can be adjusted in the OSD menu. (On Screen Display) To adjust the OSD screen: 1. Press the Menu button to enter the OSD menu. 2.
- Page 17 INSTRUCTION MANUAL ··············· 15 CONTROL AND FUNCTIONS ► PIP Menu Description All picture, sound settings and setup for the monitor can be adjusted in the OSD menu. (On Screen Display) To adjust the OSD screen: 1. Press the Menu button to enter the OSD menu. 2.
-
Page 18: Mounting Guide
16 ··············· INSTRUCTION MANUAL MOUNTING GUIDE Using the VESA standard wall mount design and the 100×100mm hole pattern on the back panel to install the LCD monitor to the wall. ► Wall-mount Installation(Option) 1. The Monitor fixing bracket to the monitor using the fixing screws provided. 2. -
Page 19: D-Sub Connector Pin Assignments
INSTRUCTION MANUAL ··············· 17 D-SUB CONNECTOR PIN ASSIGNENTS ► PIN ASSIGNMENTS Pin 1 RED VIDEO GREEN VIDEO SIGNAL CABLE DETECT BLUE VIDEO GROUND GROUND SDA (for DDC) GROUND H-SYNC (or H+V SYNC) RED GROUND V-SYNC GREEN GROUND SCL (for DDC) BLUE GROUND ►... -
Page 20: Power Management
18 ··············· INSTRUCTION MANUAL POWER MANAGEMENT ► POWER CONSUMPTION POWER CONSUMPTION MODE 17” 19” < 30W < 35W POWER OFF ≒1W ► LED INDICATOR The power management feature of the monitor is comprised of four stages: ON(GREEN) and POWER OFF(GREEN OFF). MODE LED COLOR MONITOR OPERATION... -
Page 21: Specifications
INSTRUCTION MANUAL ··············· 19 SPECIFICATIONS 17’’ 19’’ 17˝ Diagonal AM-TFT(Active-Matrix) 19˝ Diagonal AM-TFT(Active-Matrix) Pixel pitch(mm) : 0.264(H) x 0.264(V) Pixel pitch(mm) : 0.294(H) x 0.294(V) LCD-Type Brightness : 250cd/m² (Typical) Brightness : 250cd/m² (Typical) CONTRAST RATIO: 1000:1(Typical) RESPONSE TIME: 5msec(Typical) RESOLUTION (H x V) 1280X1024 @60Hz HORIZONTAL: 31~64KHz... -
Page 22: Troubleshooting Guide
20 ··············· INSTRUCTION MANUAL TROUBLESHOOTING GUIDE TROUBLE TROUBLESHOOTING TIP 1. Check that power cord or the Monitor have been connected securely into wall outlet or grounded extension cable or strip No image on display screen 2. Power switch should be in the ON position and LED is it 3. - Page 25 MEMO...
- Page 26 MEMO...
- Page 28 P/N : L39ME0397 Rev.1...
