Racing Electronics SWITCH Manual

Avoid Hearing Damage

To prevent possible hearing damage, do not use the SWITCH at high volume for a long period of time
and always lower the volume level of the device you connect to the SWITCH Audio Input port before
connecting.
FCC ID: WZ5-SWITCH
Model : SWITCH and SWITCH RACER.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) this device must accept any interference received, including interference that may
cause undesired operation.
WARNING:
Modification of this device to receive cellular radio telephone service signals is prohibited under FCC
rules and Federal Law.
The complete declaration is available online at: www.racingelectronics.com
www.RacingElectronics.com
1-800-272-7111
8 9 10 11
13
14
4 5 6
Power On/Off Button
1
Volume or Channel Up/Down Buttons
2
Programming Button
3
Channel 1 Preset Button
4
Channel 2 Preset Button
5
Scanning modes Button
6
IN (Auxiliary Audio Input), OUT (Earphone Jack)
7
Channel or Sub Channel Indicator
8
Channel Number Display
9
Volume Level Bars
10
Communication Indicator
11
Low Battery Indicator
12
Frequency Display
13
Preset or Scan Mode Selection Indicator
14
12 1
2
7
3
