- Page 1 OWNER’S MANUAL Assembly & Operating Instructions BBT 3.5KW Electric Start Sine Wave Inverter Generator MODEL NO. BBT-GEN-3.5KWINV...
-
Page 2: To The Owner
Please do NOT return the Generator without first contacting the Customer Support Department at bbt@bbta.com.au. If you have difficulty assembling this product or have any questions regarding the controls, operation, or maintenance of this Generator, please contact our Customer Support Department. SAVE THESE INSTRUCTIONS WWW.BBTA.COM.AU BBT-GEN-3.5KWINV... -
Page 3: Table Of Contents
FIG L. Fuel Tank 11 ...............................24 FIG M: Shell 12 ..............................24 FIG N. Governor 14 .............................26 FIG O: Inverter 15 ..............................26 FIG P: Electric Starter.16 ............................26 FIG Q. Control Panel 17 (FOR EU) ........................27 WARRANTY & SERVICE ........................27 YOU MAY ALSO LIKE ...........................28 BBT-GEN-3.5KWINV WWW.BBTA.COM.AU... -
Page 4: Important Safety Information
Equipment described within this manual may be optional. Some illustrations may not be applicable to your machine. WARNING! Your Responsibility—Restrict the use of this power machine to persons who have read, understood and will follow the warnings and instructions in this manual and on the machine. SAVE THESE INSTRUCTIONS! WWW.BBTA.COM.AU BBT-GEN-3.5KWINV... -
Page 5: Safety Information
Note: Use ground (earth) lead of sufficient current capacity. Diameter: 0.12mm (0.005 in)/ampere, EX: 10 Ampere – 1.2mm (0.055 in) Connection Notes • Avoid connecting the generator to commercial power outlet. • Avoid connecting the generator in parallel with any other generator. BBT-GEN-3.5KWINV WWW.BBTA.COM.AU... -
Page 6: Parts Location
19. Economy control switch 20. Voltmeter 21. DC protector 22. DC receptacle 23. Ground (earth) terminal 24. AC receptacle 25. AC receptacle L5-30R 26. AC receptacle 5-20R 27. Parallel connection control socket 28. Parallel connection socket 29. Frequency Transfer Switch WWW.BBTA.COM.AU BBT-GEN-3.5KWINV... -
Page 7: Parts Location
21. Economy control switch 22. DC protector 23. DC receptacle 24. Ground (earth) terminal 25. AC receptacle 26. AC receptacle L5-30R 27. AC receptacle 5-20R 28. Parallel connection control socket 29. Parallel connection socket 30. Frequency Transfer Switch 31. Remote control BBT-GEN-3.5KWINV WWW.BBTA.COM.AU... -
Page 8: Control Function
‘ON’ - The starter motor starts. • ‘OFF’ - The engine will not run. Brake Lever The function of brake lever is preventing generator moving. • Brake lever is not working, generator can move. • Brake lever is working, generator can’t move. WWW.BBTA.COM.AU BBT-GEN-3.5KWINV... -
Page 9: Before Operation
2. Clamp the red wire to the positive (+) terminal and the black wire to the negative (-) terminal of the battery. Do not reverse these positions. 3. Be sure the battery is installed on the battery mount tray securely. 4. Install the cover and tighten the screw. NOTE: Recommended battery: 12V6AH BBT-GEN-3.5KWINV WWW.BBTA.COM.AU... -
Page 10: Operation
2. Turn the fuel cock lever to the ‘ON’ position. 3. Turn the engine switch to the ‘RUN’ position. 4. Click remote switch to the ‘ON’ position. 5. Warm up the engine without a load for a few minutes. WWW.BBTA.COM.AU BBT-GEN-3.5KWINV... -
Page 11: Using Electric Power
C. The DC circuit protector is to be set to ‘ON’ after confirming the connection, if the protector is in ‘OFF’ position. CAUTION • Be sure the economy control switch is turned off while charging the battery. BBT-GEN-3.5KWINV WWW.BBTA.COM.AU... -
Page 12: Stopping The Engine
2. Turn the engine switch to ‘STOP’ position. Click remote switch to the ‘OFF’ position. 3. Turn the fuel cock lever to ‘OFF’. 4. Turn the fuel tank cap air vent knob counter- clockwise to the ‘CLOSED’ position. WWW.BBTA.COM.AU BBT-GEN-3.5KWINV... -
Page 13: Maintenance
Check and adjust engine idle speed Fittings / Check all fittings Fasteners and fasteners correct if necessary. Crankcase Check breather Breather hose for cracks or damage. Replace if necessary Generator Check the pilot light comes on BBT-GEN-3.5KWINV WWW.BBTA.COM.AU... -
Page 14: Engine Oil Replacement
2. Check for discolouration and remove the carbon. 3. Check the spark plug type and gap. 4. Install the spark plug. 5. Install the cover Standard electrode colour: Tan Colour Standard Spark Plug: CR4HSB (NGK) Spark Plug Gap: 0.6-0.7 mm (0.024-0.028 in) WWW.BBTA.COM.AU BBT-GEN-3.5KWINV... -
Page 15: Fuel Tank Filter
3. Use the flat-head screw driver to pry the spark arrester out from the muffler 4. Remove the carbon deposits on the muffler screen and spark arrester using a wire brush. 5. Install the muffler screen. 6. Install the cover BBT-GEN-3.5KWINV WWW.BBTA.COM.AU... -
Page 16: Troubleshooting
3. Pull the recoil starter until you feel compression. 4. Stop pulling. 5. Clean exterior of the generator and apply a rust inhibitor. 6. Store the generator in a dry, well-ventilated place, with the cover placed over it. The generator must remain in a vertical position. WWW.BBTA.COM.AU BBT-GEN-3.5KWINV... -
Page 17: Specifications
SPECIFICATIONS Model BBT-GEN-3.5KWINV Length x Width x Height 565 × 320 × 470 mm (Net), 595 × 355 × 510 (Overall) Weight 29g (Net), 32kg (Dry) Engine Type Air-cooled, 4 cycle, OHC, Fuel Engine Bore x Stroke 57.4 × 57.8 mm 149.5 cc... -
Page 18: Wiring Diagram
WIRING DIAGRAM WWW.BBTA.COM.AU BBT-GEN-3.5KWINV... - Page 19 WIRING DIAGRAM BBT-GEN-3.5KWINV WWW.BBTA.COM.AU...
-
Page 20: Exploded Diagram & Parts List
Hexagon Flange Bolts M6×100 SP-GEN-3.5KVINV-010.1 Camshaft Holder Seat SP-GEN-3.5KVINV-011.1 Copper Washer 8 SP-GEN-3.5KVINV-012.1 Hexagon Flange Nuts M8 SP-GEN-3.5KVINV-013.1 Cylinder Head Cover Seal SP-GEN-3.5KVINV-014.1 Cylinder Head Cover SP-GEN-3.5KVINV-015.1 Pipe Joint SP-GEN-3.5KVINV-016.1 Hexagon Flange Bolts M6×25 SP-GEN-3.5KVINV-017.1 Hexagon Flange Bolts M6×35 WWW.BBTA.COM.AU BBT-GEN-3.5KWINV... -
Page 21: Fig C: Crankshaft Piston 2
Intake Valve Rocker Arm Shaft FIG E. Oil Pump 4 DESCRIPTION SP-GEN-3.5KVINV-001.4 Bolt M6x12 SP-GEN-3.5KVINV-002.4 Oil Pump Sprocket Cover SP-GEN-3.5KVINV-003.4 Hexagon Flange Nuts M6 SP-GEN-3.5KVINV-004.4 Oil Pump Chain 6.35x44 SP-GEN-3.5KVINV-005.4 Oil Pump Sprocket SP-GEN-3.5KVINV-006.4 Hexagon Flange Bolts M6×25 SP-GEN-3.5KVINV-007.4 Oil Pump Assy BBT-GEN-3.5KWINV WWW.BBTA.COM.AU... -
Page 22: Fig F: Air Cleaner 5
Bolts M5×20 SP-GEN-3.5KVINV-005.7 Fan Volute Bush SP-GEN-3.5KVINV-006.7 Tapping Screw ST4.8×16-F.H SP-GEN-3.5KVINV-007.7 Starting Hub SP-GEN-3.5KVINV-008.7 Cooling Fan SP-GEN-3.5KVINV-009.7 Air Guide B SP-GEN-3.5KVINV-010.7 Air Guide A SP-GEN-3.5KVINV-011.7 Hexagon Flange Bolts M5×12 SP-GEN-3.5KVINV-012.7 Air Guide Bush SP-GEN-3.5KVINV-013.7 Hexagon Flange Nuts M5 WWW.BBTA.COM.AU BBT-GEN-3.5KWINV... -
Page 23: Fig I: Muffler 8
FIG K. Starter 10 DESCRIPTION SP-GEN-3.5KVINV-001.10 Bolt GB/T9074.17 M6×25 SP-GEN-3.5KVINV-002.10 Starter Gear Cover SP-GEN-3.5KVINV-003.10 Bearing HK1210 SP-GEN-3.5KVINV-004.10 Starter Gear SP-GEN-3.5KVINV-005.10 Starter Gear Bush SP-GEN-3.5KVINV-006.10 Starter Motor SP-GEN-3.5KVINV-007.10 Hexagon Flange Bolt M6×22 SP-GEN-3.5KVINV-008.10 Hexagon Flange Bolt M5×12 SP-GEN-3.5KVINV-009.10 Starter Relay BBT-GEN-3.5KWINV WWW.BBTA.COM.AU... -
Page 24: Fig L. Fuel Tank 11
Pan Head Screw M6×16 SP-GEN-3.5KVINV-017.13 Wheels 3" SP-GEN-3.5KVINV-037.13 Flange Bolt GB/T5789 M10×230 Flat Washer GB/T97 Φ8 Flat Washer GB/T97 Φ12 SP-GEN-3.5KVINV-018.13 SP-GEN-3.5KVINV-038.13 SP-GEN-3.5KVINV-019.13 Rubber Flat Washer Φ10×Φ20×1.5 SP-GEN-3.5KVINV-039.13 Nut GB/T923 M10 SP-GEN-3.5KVINV-020.13 Brake Part 1 SP-GEN-3.5KVINV-040.13 Pan Head Screw M6×12 WWW.BBTA.COM.AU BBT-GEN-3.5KWINV... - Page 25 EXPLODED DIAGRAM & PARTS LIST BBT-GEN-3.5KWINV WWW.BBTA.COM.AU...
-
Page 26: Fig N. Governor 14
Remote Controller Assy. SP-GEN-3.5KVINV-002.16 Remote Controller Layer SP-GEN-3.5KVINV-003.16 Tapped Screw GB/T845 ST4.8×9.5 SP-GEN-3.5KVINV-004.16 Flange Bolt GB/T5789 M6×16 SP-GEN-3.5KVINV-005.16 Regulator WYQ14-1.2 SP-GEN-3.5KVINV-006.16 Flange Nut M6 SP-GEN-3.5KVINV-007.16 Battery Layer SP-GEN-3.5KVINV-008.16 Gasket GB/T5287 Φ5 SP-GEN-3.5KVINV-009.16 Tapped Screw GB/T845 ST4.8×13 SP-GEN-3.5KVINV-010.16 Maintenance-free Battery 12V6.5AH WWW.BBTA.COM.AU BBT-GEN-3.5KWINV... -
Page 27: Fig Q. Control Panel 17 (For Eu)
Parts purchases, consumable components and accessories such as chains, carry bags, batteries, hoses, grinding discs, covers, belts, cable, wheels and blades are not covered by standard warranty. Spare Parts Spare parts are available. Please see our website (www.bbta.com.au) or contact us at bbt@bbta.com.au for more details. BBT-GEN-3.5KWINV WWW.BBTA.COM.AU... -
Page 28: You May Also Like
YOU MAY ALSO LIKE Pure Sine Wave 12V Air Compressors Inverter Generators Water Pumps Diesel Welder Generators COPYRIGHT © BIGGER BOYZ TOYZ AUSTRALIA PTY LTD. Unit 2/3 Delta Place, Albion Park Rail NSW 2527 BBT-GEN-3.5KWINV-MNL1809...
