Summary of Contents for Kraus GDA-1
-
Page 1: Installation Guide
INSTALLATION GUIDE Garbage Disposal Adapter & Flange Kit GDA-1 www.kraususa.com I Toll Free: 1.800.775.0703 I © 2017 Kraus USA Inc. I REV. October 30, 2017... - Page 2 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance, or have any problems with your product: DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com...
-
Page 3: Prior To Installation
Prior to Installation: Make sure you have all necessary parts by checking the diagram and parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775-0703 for a replacement Standard Garbage Disposal Unit Kraus Garbage Disposal Adapter... -
Page 4: Tools You Will Need
GDA-1 Diagram and Parts List: A. Strainer Cover B. Stopper C. Sink Flange D. Foam Gasket E. Rubber Gasket F. Metal Flange Adapter Exploded view Tools you will need: Safety Goggles Phillips Screwdriver... - Page 5 1. Disassemble Garbage Disposal Adapter Remove strainer cover (A), stopper (B), rubber gasket (E), and metal flange (F)
-
Page 6: Install Flange
Insert sink flange (C) in drain hole of sink with foam gasket (D) attached. Attach rubber gasket (E) and metal flange (F) from underneath the sink. Attach snap ring GDA-1 Adapter (not included) onto base of metal flange. Exploded view... - Page 7 3. Secure Flange Install mounting ring of garbage disposal unit (not included) over base of sink flange (C). Secure mounting ring by attaching snap ring onto base of sink flange (C). Tighten screws on mounting ring with Phillips head screwdriver to secure sink flange (C) to sink Installer Tip: Make sure screws are tightened in the designated areas of the metal flange (F)
- Page 8 4. Install Garbage Disposal Unit Install garbage disposal unit per manufacturer’s instructions Standard Garbage Disposal Unit Kraus Garbage Disposal Adapter A. Strainer Cover B. Stopper Remove these parts (replace with GDA-1) GDA-1 Adapter C. Sink Flange D. Foam asket E. Rubber...
-
Page 9: Replacement Part List
6. Metal Flange The step-by-step guidelines in the installation instructions are a general reference for installing a Kraus Sink. Should there be any discrepancies, Kraus cannot be held liable. It is recommended to install all Kraus products by hiring a licensed professional. - Page 10 Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user, and is not transferable to a subsequent owner.
- Page 11 (HI, AK, and Puerto Rico shipping charges may apply). International shipping fees are not included. Commercial Warranty Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and business use. All incidental or consequential damages are specifically excluded. No additional warranties, express or implied are given, including but not limited to, any implied warranty of merchantability or fitness for a particular purpose.
- Page 12 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration...
