- Page 1 ENGLISH Digital Signage Monitor VT-270MTG1 USER’S MANUAL V0.A...
-
Page 2: Table Of Contents
ENGLISH Table of Contents Important Safeguards Installing the Monitor Basic Operations Connect USB Begin Playing Update Media Content Supported Formats Digital Signage Monitor Video Output types (option) Media File Name Daily Schedule Picture File format and effects Picture File format Picture File play effect Digital Signage Monitor ON/OFF configurations Configure “Off”... -
Page 3: Important Safeguards
ENGLISH IMPORTANT SAFEGUARDS Warning: 1. Read all of these instructions. 2. Save these instructions for later use. 3. Unplug this monitor from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. 4. -
Page 4: Installing The Monitor
ENGLISH 19. The Accessory Card Reader or Accessory Card shall be connected to ITE product with Limited Power Source(LPS) Output approved by Underwriters Laboratories(UL). Installing the Monitor Unpacking Open the shipping cartons and check the contents. If any items are missing or damaged, contact your dealer immediately. -
Page 5: Supported Formats
ENGLISH Supported Formats Video: MPEG-4.10 (H.264) BP@L3, MP@L4.0, HP@L4.0 SMPTE 421M (VC-1) MP@HL, AP@L3 WMV9 MP@HL MPEG-2 MP@HL MPEG-4.2 ASP@L5 (up to HD, 1-point GMC) Audio: Image: JPG, BMP, PNG HP@L4: High Profile（1,280×720@68.3fps 1,920×1,080@30.1fps） MP@HL: Main Profile（1280x720@60fps, 1920x1080@30fps） Note: if only audio is played, the screen is blank and there will be sound only. Digital Signage Monitor Video Output Types(option) Attention: In some models without output change the output types may cause the monitor fail. -
Page 6: Media File Name
ENGLISH Example (2) Example (2) Set output to VGA 720P. Media File Name The Player treats files with uppercase and lowercase letters differently. E.g. "A.jpg" is not the same as "a.jpg". The files are listed using ascending order. If there are capitals and small letters, the player will play the files with capital letters and then the files with small letters. -
Page 7: Picture File Format And Effects
ENGLISH Example pictures: Entering 0900-1000 file name means the media file in this folder will be played from 9:00 AM to 10:00 AM Entering 1000-1030 file name means the media file in this folder will be played from 10:00 AM to 10:30 AM Entering 1100-1200 file name means the media file in this folder will be played from 11:00 AM to 12:00 PM Entering 1200-1500 file name means the media file in this folder will be played from 12:00 PM to 3:00 PM Entering 1500-1700 file name means the media file in this folder will be played from 3:00 PM to 5:00 PM... -
Page 8: Digital Signage Monitor On/Off Configurations
ENGLISH SCROLL_LEFT SCROLL_RIGHT Sequence From Left Sequence From Right Sequence From Top Sequence From Bottom Snake From Left Snake From Right Snake From Top Snake From Bottom Random Shuffle Clock Wise Shuffle Clock Wise Shuffle_Inner Counter Clock Wise Shuffle Counter Clock Wise Shuffle_Inner FLY_UP_MULTI FLY_DOWN_MULTI FLY_LEFT_MULTI... -
Page 9: Remote Controller Configuration
ENGLISH Example picture: In the example above, the Monitor will turn off at 10:00 AM and turn on at 2:00 PM. No content will be played during this period. So folders 1000-1030 and 1100-1200 will not be played. At 2:00PM (note: 14:00 in 24 hour format), the media file in 1200-1500 will be played. -
Page 10: Change Date Time
ENGLISH (Press the right arrow to display status and then press enter again to format SD card.) Change Date Time Use your control to open "Menu" and use down arrow to move to "Date Time". Then press the right arrow to move to any field for Date Time (Year/Month/Date/Hour/Minute/Second). -
Page 11: Change Aspect Ratio
ENGLISH (Press Enter to change the password. After making changes, press Enter to save) Note: The password has a maximum length of 6 digits (Press the right arrow to display status) (Press enter to make the status change possible. After making changes, press enter to save) Change Aspect Ratio Use your control to open "Menu"... -
Page 12: Lock Menu Password
ENGLISH screen displays as follows: Example pictures: (Press the right arrow to display status) (Press enter to make the status change possible. After making changes, press enter to save) Lock Menu Password Set/lock Password Use your control to open "Menu" and use the down arrow to move to "Mode Change". Press the right arrow... -
Page 13: Change Output Type(Option)
ENGLISH to move to "Password", press Enter to change the light blue highlighted area to black, then enter the password. Enter the password again in the Password Confirm field below to confirm. Note: after making changes, press "Apply" to save. After the configuration takes effect, you must enter a password when you use Menu, Output or when turning off the machine. -
Page 14: Usb Copy And Erase
ENGLISH USB Copy and Erase Copy and Erase When you restart the Monitor, the system will compare the content on the USB flash drive and the content on the SD card and automatically erase additional files in the SD and copy the files on the USB flash drive to the Example: If there are 4 files, A, B, C, and D on the SD card, and 5 files, C, D, E, F, and G on the USB flash drive, the System will delete A and B on the SD and copy E, F, and G to SD. -
Page 15: Specifications
ENGLISH Specifications Model VT-270MTG1 LCD Panel Size: 27” Pixel Pitch: 0.31125mm Brightness: 300 cd/㎡ Contrast Ratio: 3000:1 Response Time: 12ms(typ.) Maximum viewable size 27 inch (68.6cm) Video Output Analog:15-pin, D-sub connector(option) Digital: HDMI connector(option) Display area 598mmx336mm (H×V) Input voltage:...
