BLE 5.0 & WiFi Gateway Specification
BLE WiFi Gateway
Model: G1
Version: V1.3.2
Contents
Contents ...................................................................................................................................... 1
1.Overview ................................................................................................................................... 2
2.Features .................................................................................................................................... 3
3.Typical Application .................................................................................................................... 3
4.Outside View ............................................................................................................................ 4
5.Electronic Parameters ............................................................................................................... 5
Email: sales@minewtech.com
SHENZHEN MINEW TECHNOLOGIES CO LTD
Page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for MINEW G1
-
Page 1: Table Of Contents
BLE 5.0 & WiFi Gateway Specification BLE WiFi Gateway Model: G1 Version: V1.3.2 Contents Contents ............................1 1.Overview ........................... 2 2.Features ............................ 3 3.Typical Application ........................3 4.Outside View ..........................4 5.Electronic Parameters ....................... 5 Email: sales@minewtech.com SHENZHEN MINEW TECHNOLOGIES CO LTD Page 1... -
Page 2: Overview
BLE 5.0 & WiFi Gateway Specification 1. Overview G1 is a Bluetooth 5.0 low energy (BLE) to Wi-Fi connectivity gateway without the uses of smartphones or apps. The G1 gateway collects the data from iBeacon, Eddystone, BLE sensor and other BLE devices, and then sends to the local server or remote cloud server by HTTPs / MQTT/mbed (ARM) protocol with SSL and TLS certification over Wi-Fi / Ethernet / Cellular. -
Page 3: Features
● iBeacon / Eddystone / other BLE tag receiver ● BLE sensor reader / receiver ● Asset tracking ● Access control management ● Advertisement promotion ● Indoor location and position ● Industrial automation Email: sales@minewtech.com SHENZHEN MINEW TECHNOLOGIES CO LTD Page 3... -
Page 4: Outside View
E2: 300 to 500 meters MaxBeacon E6: Bluetooth ambient light sensor i3: Waterproof iBeacon & Eddystone i7 : Bluetooth accelerometer sensor C7: Credit card beacon with RFID/NFC G1: Bluetooth & WiFi gateway 4. Appearance G1-C Sign & Slots Feature Description... -
Page 5: Electronic Parameters
Powered by Micro-USB 330mA (LED strip and Wi-Fi works in the same time) 290mA (Wi-Fi only) Powered by PoE 340mA (LED strip and Wi-Fi works in the same time) 300mA (Wi-Fi only Email: sales@minewtech.com SHENZHEN MINEW TECHNOLOGIES CO LTD Page 5... - Page 6 Maximum Received Signal 0dBm Strength at <0.1% PER Frequency Deviation +/-250 kHz @BLE Antenna Flexible FPC antenna Scanning & concurrently 200 BLE devices per second process Range 300 meters in open space (max.) Email: sales@minewtech.com SHENZHEN MINEW TECHNOLOGIES CO LTD Page 6...
- Page 7 FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
