Summary of Contents for M Climate Bobbie
- Page 1 Installation Instructions...
- Page 2 Compatibility The device is designed for remote ОN/OFF switching of water heaters of all kinds. It connects to the power network 230V and has the ability to switch the power of electric water heaters with capacity to 3KW. Electrical power: AC 230 V+/-10%, 50 Hz Switching power: 3000 W - max Switching current: 16А...
-
Page 3: Inside The Box
Inside the box Bobbie temperature sensors 1m three-wire cable fasteners installation template... -
Page 4: Installation
Installation 1. Shut down the electrical power from the main fuse! Be sure that you have turned the power to the water heater off by using а phase meter. electrical switchboard ОN/OFF Water heater switch 2. Remove the bottom cover of your water heater. - Page 5 4. Put the template on the wall. The template shows you where you should mark the spots for fixing Bobbie on the wall. For smooth surfaces (like faience), you can use double sided foil.
- Page 6 Installation 5. Mount Bobbie on the wall. Use the fasteners or double sided foil to make sure that the device is well attached to the wall. 6. Mount the wires that you’ve marked in t.3 Connect wire L to position 1, wire N to...
- Page 7 Installation 7. Connect the extra wire. The extra wire connects Bobbie to your water heater. Mount the red wire to position 2, the blue one to position 3 and the yellow with green strips to postition 4. 8. Mount the extra wire to your water heater.
- Page 8 Installation 9. Place the bottom cover of your water heater. Use the instructions of the manufacturer. 10. Connect Bobbie’s sensors. Connect the cable of the sensors into position 5.
- Page 9 Installation 11. Fixate every cables in the box. Put every cable in its place and tighten them with the bracket. 12. Place Bobbie’s front cover. Place Bobbie’s front cover to make it look out of the box.
- Page 10 Installation 13. Place the sensors to the pipes of your water heater. Mount the red sensor to the hot water pipe and the blue one to the cold water pipe. 14. Turn on the electricity from the main switchboard. Turn ON the switch of your water heater. electrical switchboard ОN/OFF Water heater switch.
- Page 11 Installation 15. Download Bobbie’s mobile application. You can download the app to iOS and Android from: www.seebobbie.com/app Anything left unclear? For more information and questions about the product, visit: www.seebobbie.com...
