Assistive Technology Services SKY Angel 911 FD User Manual

Charging Contacts

DEVICE CHARGING:

For the first time of use, please fully charge the unit for at least 2-3 hours.
Using the USB charger or using docking station to charge
 Place the device on the docking station.
 Connect the Micro USB side of the cable to the docking station port and connect the other end
of the cable to the designated AC power source (USB/AC adaptor)

SWITCHING THE DEVICE ON AND OFF:

 To turn on the device: press the side power button for 1 second. All the LEDs will flash
rapidly. Device can be also turned on automatically by charging via USB or putting it into the
docking station.
 To turn off the device: press and hold the side button and SOS button together for 1 second
until the LEDs is off.

WATERPROOF:

SkyAngel 911 is 100% waterproof and can be briefly worn in the shower or even submerged under
water for short periods of time. Do not allow the device to be soaked for prolonged periods of time.
PLEASE NOTE: Do not remove the back cover at any time; this will break the waterproof seal. Also
removing the back cover voids any and all warranties.

WHAT DO THE FLASHING LIGHTS ON THE SIDE OF THE UNIT MEAN?

Charging Status – Blue Light:
 Blue light is on solid; unit is charging
 Blue light is blinking quickly; unit has less than 15% power and should be recharged
 Blue light is blinking very slowly; unit is fully charged and has GPS satellite signal
Cellular Status – Green Light:
 Green light single flash every 3 seconds; unit is connected to a cellular network
 Green light is flashing very rapidly; unit is contacting 911
SKY Angel 911 FD User's Guide
Speaker
LED Indicators
SOS Button
Microphone
ON / OFF
Micro USB
