INSTALLATION AND OPERATION MANUAL
Industrial DC-Battery Power Management System
Thank you for purchasing NetWave® from ComNet. This manual
will cover how to install hardware on your enclosure, configure
batteries, cabling, and mounting of the enclosure.
The NetWave® NWKBB100 DC-Battery Power Solution provides
consistent power for your devices in locations where power
is on a timer or they have frequent blackouts or brownouts.
The NWKBB100 supports AC input ranging from 110 to 277
VAC, and can also support higher voltages using a Step Down
Transformer. The intelligent controller distributes power to the
load and batteries when AC power is available and instantly
switches over to DC output only when AC power is lost. The kit
includes valve-regulated lead-acid batteries, outdoor enclosure,
mounting bracket and Smart DC-Battery Power Controller. The
aluminum outdoor enclosure has two 180° door hinges and
a pad lockable latch for security. The enclosure has built in
mounting brackets that support pole and wall mounting.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NWKBB100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Comnet NWKBB100

Summary of Contents for Comnet NWKBB100

  • Page 1 The NWKBB100 supports AC input ranging from 110 to 277 VAC, and can also support higher voltages using a Step Down Transformer.

  • Page 2: Related Documentation

    Related Documentation The following documentation is also available: » NWKBB100 Datasheet Website For information on ComNet’s entire product line, please visit the ComNet website at http://www.comnet.net Support For any questions or technical assistance, please contact your sales person (sales@comnet.net) or the customer service support center (techsupport@comnet.net)

  • Page 3: Table Of Contents

    INSTALLATION AND OPERATION MANUAL NWKBB100 Contents About This Guide Related Documentation Website Safety Overview Legal Information 1.0 Introduction 2.0 Installation Preparing the Enclosure Mounting the Enclosure Battery Configuration 3.0 Controller Configuration TECH SUPPORT: 1.888.678.9427 INS_NWKBB100_REV– 06/10/13 PAGE 3...

  • Page 4: Overview

    Copyright © 2016 Communication Networks, LLC (dba ComNet). All rights reserved. Disclaimer ComNet reserves the right to make changes in specifications at any time without notice. The information furnished by ComNet in this material is believed to be accurate and reliable. However, ComNet assumes no responsibility for its use.

  • Page 5: Introduction

    The NWKBB100 supports AC input ranging from 110 to 277 VAC, and can also support 347 VAC and 480 VAC with an optional Multi Tap Power Transformer. The intelligent controller distributes power to the load and batteries when AC power is available and instantly switches over to DC output only when AC power is lost.

  • Page 6: Installation

    NWKBB100 2.0 Installation Preparing the Enclosure The NWKBB100 enclosure has integrated mounting brackets and a bolt on mounting plate simplifying installation. Prepare the mounting plate for DIN Rail installation by loosening the screws in the top corners and removing the mounting plate (the appearance of the included mounting plate may vary).

  • Page 7: Mounting The Enclosure

    NWKBB100 Mounting the Enclosure The NWKBB100 has rackmounts welded onto the enclosure for ease of installation. The included hose clamps will allow you to mount the enclosure on up to a 3 inch diameter pole or you can wall mount the unit using screws appropriate to your mounting surface.

  • Page 8: Battery Configuration

    INSTALLATION AND OPERATION MANUAL NWKBB100 Battery Configuration One the DIN Rail has been installed and the enclosure has been mounted, setup the batteries. We provide four 12VDC batteries that will need to be configured in series since our controller will output 48VDC.

  • Page 9: Controller Configuration

    NWKBB100 3.0 Controller Configuration The Uninterruptible power supply can be used in many different applications. We recommend the following settings for the NWKBB100 Kit. Leave the Charging Current set to 50%. Set Jump settings to Sealed Lead High. Jumpers are on the bottom right of the controller.
  • Page 10 INSTALLATION AND OPERATION MANUAL NWKBB100 Connect your device to the 48VDC @ 5A power source on Pins 1 and 2. Connect AC Power Source to the Controller Once AC power is detected, the LEDs on the front of the controller will light up.
