Setting lever for position: "Tool
open" and "Tool in work position"
17 Driver roller 30°
18 Driver roller 75°
Seam locker TruTool F 301
E607EN_01.DOC
2.
Description
1
60
17
21 Guide rail
25 Roller (horizontal)
42 Handle
60 Suspension eyelet
347
61
62
25
18
61 Lever
62 Safety lever
347 Sleeve
Description
42
Fig. 52523
