SWC2001W USER MANUAL
[1] Turing the Phone On and Off
1. TURNING THE PHONE ON
Press and hold End/Power Key.
Then phone is locked if "a lock" icon is showed.
2. TURNING THE PHONE OFF
Press and hold End/Power Key.
[2] How to use the Menu
1. In the standby screen, press Soft Right Key.
2. In the menu, use scroll keys(Right, Left, Up, Down Key) to view the menu
selections.
If you press an hold the scroll keys, the menu scrolls automatically.
3. To go back to previous screen, prss Soft Left Key.
1
MENU SUMMARY
1. Calls
1: Incoming
2: Outgoing
3: Air Time
1: Last Call
2: Home Calls
3: Roam Calls
4: All Calls
5: Reset AirTime
2. Phone book
1: Fast Search
2: Recall by name
3: Recall by mem
4: Recall by num
5: Grouping
6: Add Entry
7: Emergency #
8: Memory Status
9: Int Call
#. My Phone #
3. Schedule
1: Appointed Time
2: Alarm
3: Anniversary
4 Schedule
5: To do List
6: D-Day
7: Time Signal
8: Calendar
9: Set Time
10: Alarm Sound
4. Sound
1: Ring Tone
2: Ring Type
3: Ring Volume
4: Key Volume
5: Tone Length
6: Voice Volume
7: Con. Fade Volume
2
Advertisement
Table of Contents
Summary of Contents for Sewon SWC-2001W
-
Page 1: Menu Summary
SWC2001W USER MANUAL MENU SUMMARY 1. Calls 1: Incoming 2: Outgoing 3: Air Time 1: Last Call 2: Home Calls 3: Roam Calls 4: All Calls 5: Reset AirTime 2. Phone book 1: Fast Search 2: Recall by name 3: Recall by mem 4: Recall by num 5: Grouping 6: Add Entry... -
Page 2: Basic Function
8: Mike Volume BASIC FUNCTION 9: Alert 5. Pocket Book 1: Calculator 1. MAKING A CALL 2: World Time Enter the Phone number. 3: Converr Unit To Erase the last number entered: Press Clear key. 4: Personal Note To Make a Call : Press [SEND] Key. 5: STOP Watch Press [End/Power] Key to end the call 2. - Page 3 5. CALL OPTION VOICE MAIL AND TEXT MESSAGE(SMS) 5-1 Shortened Dial Function This function enable you to make a call directly with the telephone number saved in the memory without pressing SEND Key. 1. Receiving a message By pressing Down Key +1 or +2, message can be confirmed(+1 for voice message and +2 5-2 Last dialed numbers for text message).
-
Page 4: Functions During A Call
FUNCTIONS DURING A CALL MEMORY FUNCTION 1. Sending your number [1] How to Store a Phone Number By pressing Soft Right Key+1 during conversation over the phone, a DTMF tone is transmitted. 1. Enter the phone number(more than 3 digits) you want to store and press Soft Right Key. - Page 5 [3] How to Make a call using a Stored Phone Number 7. Emergency# This is used for registering the emergency phone number. 1. ONE TOUCH DIALING 8. Memory Status Press and hold corresponding memory number for more than 1 second. This enables to know how many addresses were used of the addresses which can be stored.
- Page 6 6. Auto Answer SETUP This function answers an incoming call automatically after a number of rings that the user sets. 7. Data Service 1. Auto Retry If you setup Auto Retry from Soft Right Key +0+1, when dialing is failed and not 7-1 Service Type through, dialing is automatically tried five times.
- Page 7 GAMES(OTHELO) CALLS 1. Game Start 1. Incoming Press Soft Right Key, then *, and then 1. Menu+1+1 You can skip if you press any key(except ’#’ Key, Send Key, End/Power Key) in the Details of the phone numbers received up to now can be read. course of starting.
- Page 8 SCHEDULE SOUND 1. Appointed Time 1. Ring Tone Alarm is setup by designating the time which is after several hours from the present Ring Tone can be setup using Bell 1-Bell 4 and Melody 1-Melody 7. time. 2. Ring type 2.
- Page 9 9. Alert POCKETBOOK 9-1 Connect Tone Establishing Connect Tone, alarm sounds prior to getting through when 1. Calculator dialling. 2. World Time 9-2 Fade Alert Alarm sounds when calling is cut off. 3. Convert Unit Press the Soft Right Key, then 5 and then 3. 9-3 Minute Beep Then, entering the figure based on the unit of a below column, the unit is converted by Alarm sounds every one minute in a phone call state.
-
Page 10: Voice Service
SECURITY VOICE SERVICE For entering the Security Menu, password should be entered. 1. VDIAL LIST Press Soft Right Key , then7, then 1. 1. How to lock your phone The list of Voice Dial can be seen. Press Soft Right Key, then 6, then Enter SECURITY CODE, then 1. So as to use Voice Dial, the user’s voice should be registered in Soft Right Key +7+6. -
Page 11: Web Browsing
6. Press 1~9, You can lauch it on each website marked on WEB BROWSING each number. 7. Press Down_Key loglong, You can see web browser inbox. [1] Web-Access 8. Press CLR_Key . You can go back to the previous page. 9. -
Page 12: Fcc Rf Exposure Information
Body-worn Operation This device was tested for typical body-worn operations using the Sewon SWC-2001W belt-holster. To comply with FCC RF exposure requirements, use only Sewon approved accessories. When carrying the phone with the power on, use only the specific Sewon belt- holster that has been tested for compliance.
