Trigger connection

Power Box DS2 Sources is equipped with 12V trigger-out socket (jack 2.5mm) to turn on/off a Pro-Ject product
with trigger input socket.
!
Do not use the trigger output for any other connections for which it is not designed.

Main power switch

The toggle switch on the front panel turns the unit on or off. The blue LED above the switch shows that the unit
is switched on.
Technical specifications Pro-Ject Power Box DS2 Sources
Output voltage / current (socket diameter):
Trigger output:
Dimensions W x H x D with sockets:
Weight:

Service

Should you encounter a problem which you are not able to alleviate or identify despite the above information,
please contact your dealer for further advice. Only when the problem cannot be resolved there should the unit
be sent to the responsible distributor in your country.

Warranty

The manufacturer accepts no responsibility for damage caused by not adhering to these instructions
for use. Modification or change to any part of the product by unauthorized persons, release the
manufacturer from any liability over and above the lawful rights of the customer.

Copyright, trademarks

Pro-Ject Audio Systems is a Registered Trademark of
H. Lichtenegger.
This guide was produced by: Pro-Ject Audio Systems
Copyright 2017. All rights reserved.
©
2x 9V/2A (1,3mm), 3x 18V/1A(2,5mm), 1x 15V(2,1mm)
2,5mm jack
Aluminium 206 x 71 x 209mm
Wood 240 x 72 x 209mm
Aluminium 3000g, Wood 3400g
© Pro-Ject Audio Systems · Pro-Ject Power Box DS2 Sources · Revision 2018.12.13
The information was correct at the time of going to
press. The manufacturer reserves the right to make
changes to the technical specification without prior
notice as deemed necessary to uphold the ongoing
process of technical development.
