Summary of Contents for Exos Mini
- Page 1 Revised: 2015-01-07 User Manual Exos Mini Pin Bone Remover...
- Page 2 Thank you for choosing a hand held Pin Bone remover from Exos. We hope you will find a tool that gives you the speed, yield and efficiency that you expect from a professional company. When you rinse the equipment often and keep it clear from grease you ensure the equipments possibility to grab the bones.
- Page 3 EXOS MINI SPECIFICATIONS Weight, handle 300gr Effect Voltage 100 – 240 V AC Frequency 50 – 60 Hz Motor, brushless 12V DC Fixed speed 150 rpm Cable length, handle to outlet 1,5 m...
- Page 4 Watch out! • Never put your fingers close to the drums while working...
- Page 5 Placing the fillet right • In order to work most efficient, place the fillet with its head closest to you • You can then push or hold back the equipment with little risk of imbalance...
- Page 6 Raising the bones • Use the bone guide holder if you want to put up the end of the bones • Slant the machine so that only the bone guide holder touches the fish • Press down and move your hand towards the tail • ...
- Page 7 Placing the machine correct (1) Pressure Movement, by the machine • Make sure the whole area of the machine touches the fish • Press downwords • Let the machine move by itself over the fillet. Do not push it forward! • ...
- Page 8 Placing the machine correct (2) Movement • Make sure the whole area of the machine touches the fish and press while moving the machine over the fish • Twisting the machine forward or backward may cause gapping or missed bones...
- Page 9 Placing the machine correct (3) • Always strive to get the drum 90 towards the bone so you can pull it out in the same direction as its fitted in the fish. An incorrect angle may cause gapping • Turn the machine clockwise on a left fillet and anti-clockwise on a right fillet...
- Page 10 Rinsing the equipment regulary • When the machine is full of bones or grease turn the machine away from the fish and press the water device • If bones are stuck; try flush more often – or – try flush less often: bones from underneath may press up the stucked bones...
- Page 11 nt after use Cleaning the equipment after use ne guide • Use your fingers to remove the drum and bone guide • Wash the parts and assemble in reverse order...
-
Page 12: Spare Part List
Spare part list... - Page 13 Manufactures declaration of conformity As manufacturer, we declare that the equipment follows the provision of the directives stated below: 1 Manufacturer Exos AB Ekeby Bruk SE-752 75 Uppsala SWEDEN 2 Type of equipment Pin Bone Remover EC-directive applied to the product...
- Page 14 Exos AB, Uppsala, Sweden WWW.EXOS.SE...
