11-pin Handgun Rack
Double Barrel Rest
Defender 17 Includes:
11-pin Handgun Rack (x1)
Single Barrel Rest (x6)
Top Shelf Support Bracket (x2)
Top Shelf (x1)
Joggle Adjustment Tool (x1)
Defender 25 Includes:
3-pin Handgun Rack (x3)
Double Barrel Rest (x9)
Top Shelf Support Bracket (x2)
Top Shelf (x1)
Joggle Adjustment Tool (x1)
SEE REVERSE FOR INSTALLATION INSTRUCTIONS.
MODULAR PANEL SYSTEM PARTS LIST
®
3-pin Handgun Rack
(Defender
Single Barrel Rest
(Defender
16-gauge steel shelf in Defender
Defender 34 Includes:
11-pin Handgun Rack (x2)
Double Barrel Rest (x12)
Top Shelf Support Bracket (x2)
Top Shelf (x1)
Joggle Adjustment Tool (x1)
Defender 44 Includes:
11-pin Handgun Rack (x2)
Double Barrel Rest (x12)
Top Shelf Support Bracket (x4)
Top Shelf (x2)
Joggle Adjustment Tool (x1)
PART DESIGN MAY VARY FROM IMAGES SHOWN.
25 only)
®
17 only)
®
Series not shown.
®
Modular Panel System Setup Instructions
Top Shelf Support Bracket
(Defender
series only)
®
Joggle Adjustment Tool
Evolution 36/55 Includes:
11-pin Handgun Rack (x1)
Double Barrel Rest (x12)
Joggle Adjustment Tool (x1)
