Introducing Eve Smoke
1
Mounting plate
Ring marker
Test button
Technical Information
• Alarm type: optical smoke alarm
• Average area covered: 50 m²
• Area of use: indoors
• Power supply: lithium battery, 2 x 3 V,
integrated, non-replaceable,
10-year service life
• Alert: alarm status, faults
• Integrated warning sound on detection:
85 dB(A) at 3 m
LED alignment arrow
Emergency light
Status LED
• Integrated test and fault alarm: 75 dB(A) at 1 m
• Operating temperature: -10°C to + 55°C
• Storage temperature: -10°C to + 65°C
• Protection rating: IP22
• Dimensions (D x H): 116 mm x 49 mm
• Weight: 255 g
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for EVE Smoke
Summary of Contents for EVE Smoke
- Page 1 Emergency light Test button Status LED Technical Information • Alarm type: optical smoke alarm • Integrated test and fault alarm: 75 dB(A) at 1 m • Average area covered: 50 m² • Operating temperature: -10°C to + 55°C • Area of use: indoors •...
- Page 2 7:13 - 16:00 Eve Smoke will continue to alert you until no smoke or heat is detected, or until the alarm is silenced. A smoke and heat alarm will be displayed in the Eve app. Using the Home app, you can also enable alarm 4:09 - 10:00 notifications by accessing the Details view of Eve Smoke.
-
Page 3: Installation And Setup
• In a kitchen, where steam is produced by cooking • In dusty, uninhabited areas (e.g. your garage) To use Eve Smoke exclusively as a heat alarm, apply a screwdriver to remove the cover as shown in the illustration, and set the switch to ON. - Page 4 • Less than 1 m away from warm air, air conditioning, or ventilation outlets, as these may dissipate smoke If you cannot install Eve Smoke horizontally on the ceiling, install it: • Less than 6 m away from a fireplace or a wood-burning stove, as the smoke emitted via combustion may trigger unnecessary alarms •...
- Page 5 The LED alignment arrow shows you the direction of the Status LED after installation. Use the Eve app to conveniently test Eve Smoke at any time. Alternatively, trigger a test alarm by pressing and holding the Test button until you hear the 2nd sound, then release the button.
-
Page 6: Pausing Alarms
You can deactivate Eve Smoke for approximately 15 minutes to avoid triggering an unnecessary After smoke or heat has triggered an alarm, you can use any of the following methods to mute it: alarm when engaging in activities that may create dust or smoke (dusting, cleaning a fireplace, roasting food, etc.). -
Page 7: Battery Fault
Eve Smoke constantly checks itself. Moreover, in addition to keeping you updated on smoke and heat alarms, it also alerts you of any potential faults. Faults are displayed in the Eve app as follows: To avoid waking you while you sleep, battery or detection fault sounds are suppressed when it is dark. You will be alerted of a fault within 10 minutes after dawn or 8 hours after the fault occurred. - Page 8 Overview of status alerts It is essential that you clean Eve Smoke regularly. The openings on Eve Smoke must be cleaned at least once a year in accordance with relevant smoke alarm standards, such as DIN 14676. Only use a cloth -...
- Page 9 Please retain the documentation supplied with this product for its entire service life. This product is only to be used at home or similar residential areas in accordance with DIN 14676. It is not to be used in a fire detection system in accordance with DIN 14676. This device conforms to the general requirements and further relevant provisions of the 2014/53/EC directive, the requirements of the EU regulation no.
