Headboard (A) 1 pc
Wing (B) 2 pcs
Slat (E) 1 set
size:M8*70mm
Threaded bolt (b) 8 pcs
Flat washer (c) 6 pcs
Ø:5mm
Allen wrench (g) 1 pc
Wrench (h) 1 pc
Step 1. Put the Headboard (A) upon to the L shape legs of Wing (B) and install the Wings, tighten the Inner hexagon screws (a), and veil the dust cover.
Step 2. Screw in the Threaded bolt (b) to the Wing (B) and Footboard (C), and tighten the Threaded bolts by hand.
Brittany Bed Assembly Instruction
Footboard (C) 1 pc
Middle leg rail (F) 1pc
size:Ø 22mm
size:Ø 8mm
Bent washer (d) 6 pcs
Ø:14mm
Side rail (D)
2 pcs
size:40*40*185mm
Middle leg (G) 2pcs
Inner hexagon screw (a) 8 pcs
Cup nut (e) 8 pcs
Plastic washer (f) 2 pcs
size:M8*30mm
Advertisement
Table of Contents
Related Manuals for Down East Brittany
Summary of Contents for Down East Brittany
- Page 1 Brittany Bed Assembly Instruction Headboard (A) 1 pc Wing (B) 2 pcs Footboard (C) 1 pc Side rail (D) 2 pcs size:40*40*185mm size:M8*30mm Slat (E) 1 set Middle leg rail (F) 1pc Middle leg (G) 2pcs Inner hexagon screw (a) 8 pcs size:M8*70mm size:Ø...
- Page 2 little blocks facing Step 3. Install the Side rail (D) into the Wing (B) and Footboard (C) as picture shown, make sure the little blocks is facing upwards. Tighten the Cup nut (e), Bent washer (d) and Flat washer (c) with Wrench (h). Step 4.
