Summary of Contents for RSR TB311HWW
- Page 1 For more indepthinformation, go to our Web site www.richsound.com TB311HWW USER MANUAL...
-
Page 2: Table Of Contents
Contents Important Safety Instructions .....................3 Safety .......................................3 Warning ....................................4 Identifying the Parts ......................5 Main Unit ....................................5 Wireless Subwoofer ................................5 Remote Control ...................................5 Preparations ..........................6 Prepare the Remote Control ............................6 Replace the Remote Control Battery ...........................6 Connections ...........................6 Use the HDMI ARC socket ..............................6 Use the OPTICAL Socket ..............................7 Use the AUX Socket ................................7 Connect to Power ................................7... -
Page 3: Important Safety Instructions
Important Safety Instructions CAU TI O N and a third grounding prong. The wide blade or the third prong is provided for RISK OF ELECTRIC your safety. If the provided plug does not fit SHOCK DO NOT OPEN into your outlet, consult an electrician for A VI S replacement of the obsolete outlet. - Page 4 • Caution: DO NOT INGEST BATTERY,CHEMICAL BURN HAZARD Use of controls or adjustments or The remote control supplied with this performance of procedures other than product contains a coin/button cell battery. those described herein, may result in If the coin/button cell battery is swallowed, hazardous radiation exposure or other it can cause severe internal burns in just unsafe operation.
-
Page 5: Warning
FCC INFORMATION (for US customers) Warning: - This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. - Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. ” NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 6: Identifying The Parts
Identifying the Parts Main Unit 1 Remote Control Sensor 2 LED Indicators • Red indicator: In STANDBY mode. • Green indicator: In AUX mode. • Yellow indicator: In Optical mode. • Blue indicator: In Bluetooth mode. • White indicator: In HDMI ARC mode. button Switch the unit between ON and STANDBY mode. -
Page 7: Preparations
Preparations Prepare the Remote Control The provided Remote Control allows the unit to be operated from a distance. • Even if the Remote Control is operated within the effective range (6m), remote control operation may be impossible if there are any obstacles between the unit and the remote control. •... -
Page 8: Use The Optical Socket
Tips: • Your TV must support the HDMI-CEC and ARC function. HDMI-CEC and ARC must be set to On. • The setting method of HDMI-CEC and ARC may differ depending on the TV. For details about ARC function, please refer to your TV owner’s manual. •... -
Page 9: Pairing The Wireless Subwoofer With The Main Unit
Pairing the Wireless Subwoofer with the Main Unit Automatic pairing The subwoofer and soundbar will automatically pair when both units are plugged into the mains sockets and turned on. No cable is needed for connecting the two units. When the subwoofer is pairing with the main unit, the Pair Indicator will flash fash. When the subwoofer is paired with the main unit, the Pair Indicator will light up. -
Page 10: Select Modes
Select Modes Press the SOURCE button repeatedly on the unit or the AUX, OPTICAL, HDMI ARC and BT (Bluetooth) buttons on the remote control to select the desired mode. • Red indicator: In STANDBY mode. • Green indicator: In AUX mode. •... -
Page 11: Listen To Music From Bluetooth Device
Note: The operational range between this player and a Bluetooth device is approximately 8 meters (without any object between the Bluetooth device and the unit). Before you connect a Bluetooth device to this unit, ensure you know the device’s capabilities. Compatibility with all Bluetooth devices is not guaranteed. -
Page 12: Troubleshooting
Troubleshooting To keep the warranty valid, never try to repair the system yourself. If you encounter problems when using this unit, check the following points before requesting service. • No power - Ensure that the AC cord of the apparatus is properly connected. - Ensure that there is power at the AC outlet. -
Page 13: Specifications
Specifications Model Name HT-SBW160 Soundbar Bar Power Supply 100-240V 50/60Hz Power Consumption USB (Service Only) 5V==500mA Dimension (W x D x H) 900 x 86 x 45 mm Audio input sensitivity 500mV Frequency Response 120Hz - 20KHz Impedance 8 Ω Bluetooth Version V 4.2...
