Table of Contents

MWBPT
Owner's Manual
Wireless Belt Pack Transmitter
MWBPT
UHF 100 Frequency
Wireless Belt Pack Transmitter
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
– 1 –
AtlasIED.com
Specifications are subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MWBPT and is the answer not in the manual?

Questions and answers

Summary of Contents for Atlas IED MWBPT

  • Page 1 MWBPT Owner’s Manual Wireless Belt Pack Transmitter MWBPT UHF 100 Frequency Wireless Belt Pack Transmitter 1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A. Telephone: 800.876.3333 • Fax: 800.765.3435 – 1 – AtlasIED.com Specifications are subject to change without notice.
  • Page 2 Wireless Belt Pack Transmitter Description The AtlasIED MWBPT wireless belt pack transmitter is the ideal choice for a variety of applications ranging from classrooms and conference rooms to lecture halls and live presentations. The MWBPT works with either the MWOEM headset microphone or MWLM lavalier microphone. High and low impedance gain adjustments are included to ensure optimal pickup for a variety of applications.

  • Page 3: Parts And Functions

    MWBPT Owner’s Manual Wireless Belt Pack Transmitter Parts and Functions 10 11 13 1. Antenna 2. LCD Display 3. Cover Release Button 4. Synchronizing Button 5. Menu Button 6. Setting Button 7. High-impedance Gain Control (GT) 8. Low-impedance Gain Control (MT) 9.
  • Page 4 Gain control enables the user to set different output levels. When using the MWBPT with an instrument with high impedance, like a guitar, set the Gain control to GT8. When using the MWBPT for voice amplification, low impedance, set the Gain control to MT9.
  • Page 5 MWBPT Owner’s Manual Wireless Belt Pack Transmitter Synchronizing Channels on the Receiver and Transmitter Align infrared areas of the receiver and transmitter within 12" (30cm). < 12" Figure 3 A. Changing the receiver’s channel 1. Press the synchronizing button on the belt pack (Fig 4).

  • Page 6: Channel Setting

    MWBPT Owner’s Manual Wireless Belt Pack Transmitter Channel Setting 1. Use MENU button to go to the CHANNEL | FREQUENCY page (Fig 8). 2. Press and hold the SET button for 3 seconds, then the upper-right channel number will flash to allow changes to be made (Fig 9).
  • Page 7 Wireless Belt Pack Transmitter Important: Use only NiMH rechargeable batteries when using non-alkaline type batteries. Lithium Ion or other rechargeable batteries are not compatible with the MWBPT. NiMH must be selected when using rechargeable batteries. Never select AKLN (alkaline) when using rechargeable batteries.

  • Page 8: Limited Warranty

    Service Should your MWBPT require service, please contact the AtlasIED warranty department at 1-877-689-8055, ext. 277 or www.atlasied.com/support to obtain an RA number. AtlasIED Tech Support can be reached at 1-800-876-3333 or www.atlasied.com/support Visit our website at www.AtlasIED.com to see other AtlasIED products.

Table of Contents
