Wood Chipper
User Manual
[Revision 3.0 October 2017]
READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND
MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in
appearance, assembly, inclusions, specifications, description and packaging.
The product is NOT supplied with engine oil, although traces of oil from the manufacturing process
may be present. It is essential to add adequate engine oil of the correct type to the engine before use.
Failure to add engine oil will void the product
warranty.
Advertisement
Table of Contents
Summary of Contents for Michigan USA Raptor
- Page 1 Wood Chipper User Manual [Revision 3.0 October 2017] READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in appearance, assembly, inclusions, specifications, description and packaging.
-
Page 2: Table Of Contents
Shredding ................................ 8 Maintenance ................................. 9 General Maintenance ............................9 Belt Removal ..............................10 Draining the Fuel ............................10 Greasing the Blade Barrel ..........................10 Transporting and Storage ..........................10 Troubleshooting ..............................11 Specifications ..............................12 E&OE © 2017 Michigan USA... -
Page 3: Safety
Transporting the Machine • Always turn off the engine. • The engine should be turned off when the machine is moved between areas and when transporting or storing the machine. E&OE © 2017 Michigan USA... -
Page 4: Fuelling
Before proceeding to adjust or repair the machine, be sure to stop the engine and detach the spark plug. • Never attempt to make engine adjustments while the unit is running or strapped to the operator. Always make engine adjustments with the unit resting on a flat, clear surface. E&OE © 2017 Michigan USA... -
Page 5: Included Items
Included Items No. Part Part No. Part Inflatable wheels 25mm bolt Discharge Chute Stop Washer Chassis frame Washer 20mm bolt Motor Crusher room Cutter wheel Handle Flat washer Belt cover Knob Hopper Chute Belt tension wheel E&OE © 2017 Michigan USA... -
Page 6: Set-Up
2. One leg (6) at a time, bolt the boot to the chassis (8) using another flat washer (4) and nut (5). 3. Secure both feet to the chassis hand tight plus half a turn. E&OE © 2017 Michigan USA... -
Page 7: Assembling The Chutes
3. Slide the Belt tension wheel (18) into its axle on the front of the machine. 4. Bolt the Belt tension wheel to the machine using one 20mm bolt (3) and washer (2). E&OE © 2017 Michigan USA... -
Page 8: Chute Safety Switch Installation
Ensure that the safety switch arm is fully pushing the [black] microswitch "in", otherwise, the engine will not start. If the safety switch arm is not fully pushing the microswitch "in", remove the safety switch assembly and bend the arm as shown below (approximately 10mm should be ample), then re-install the safety switch E&OE © 2017 Michigan USA... -
Page 9: Operation
5. Pull the starting cord until the engine starts. 6. Once the engine has warmed up slide the choke lever right to the “OPEN” position. 7. Adjust the throttle to achieve the desired operating speed. E&OE © 2017 Michigan USA... -
Page 10: Chipping
5. Keep watching the area under the machine to ensure that the shredded material has not built up to the point where further shredded material cannot escape. This may prevent proper discharge and could cause kickback of material through the feed opening. Move the machine backwards a short distance as material builds up underneath. E&OE © 2017 Michigan USA... -
Page 11: Maintenance
Harsh conditions such as high temperature operation, higher than normal loads and dusty applications will require reduced service intervals. • Max. continuous running time without cool-off I daily check assuming full oil level and no noticeable oil usage or other concerns- 4hrs (except diesel). E&OE © 2017 Michigan USA... -
Page 12: Belt Removal
6 months, depending on usage. Transporting and Storage WARNING! Do not operate the machine while it is on a vehicle. Take the machine off the vehicle and use it in a well ventilated place. E&OE © 2017 Michigan USA... -
Page 13: Troubleshooting
Chipping Blade damaged Check blades and replace if needed Excessive vibration Debris jammed into flail blades Check flails and remove any debris Uneven surface Move unit to a flat surface E&OE © 2017 Michigan USA... -
Page 14: Specifications
Oil Capacity 0.6 Litres Oil Type 10W-30, 10W-40, 15W-30 OR 15W-40 Maximum Branch Thickness 60mm Wheel Diameter 21cm Please note, this model is not designed for tough fibrous material, such as flax, vines or palm fronds. E&OE © 2017 Michigan USA... - Page 15 ©2017 Michigan USA. All rights reserved. No part of this document, including descriptive content, concepts, ideas, diagrams or images may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, scanning or recording, or any information storage and retrieval system, without express permission or consent from the publisher.
