Summary of Contents for HBX ECO-0550
- Page 1 Installation Manual Central Processing Unit 0550 Version 2.00 ECO-0550 HBX Control Systems Inc.
-
Page 2: Table Of Contents
Technical Data and Dimensions ............2 Wiring & Installation ................3 Wiring ....................... 3 Installation ....................3 Programming ECO-0550 .................4-5 Navigating the ECO-0550................ 4 Control Mode.................... 4 Setup Menu....................5 Geothermal Mode Programming............6-13 Multicolour backlit display............... 6 Screen Colours..................6 Status Screen..................... -
Page 3: Introduction
DESCRIPTION The ECO-0550 is designed to be a stand-alone Outdoor Reset Control device. The purpose and function of the ECO-0550 is to provide control for Geothermal applications. It can manage single tank applications as well as applications with seperate hot and cold tanks. -
Page 4: Technical Data And Dimensions
TECHNICAL DATA Relays: 240VAC 5A Max Specifications: Input: 3 x Thermistor Input 120VAC 15A Max ECO-0550 (10K Ohm) Central Processing Unit 2 x Miscellaneous Input Signal 3 x Relay Outputs (240VAC 5Amps) Dry Contacts 1 x 2Amp Dry Contact Input: 120VAC +/- 10% 50/60Hz 15A Max... -
Page 5: Wiring & Installation
Supply Power 120 VAC Installation The ECO-0550 is designed to be wall mounted or installed in a separate electrical enclosure. The unit should be mounted inside and protected from falling water and high humidity conditions. With all the covers in place it is designed to protect any individual from accidental electrical shock. -
Page 6: Programming Eco-0550
The ENTER button is used to access the setpoint menu and select a setting. ENTER CONTROL MODE The programming instructions for the ECO-0550 are currently selectable in the mode listed below. When the control is first plugged in you are asked to select which control mode you would like your ECO-0550 to operate in. To select your control mode simply use the ▲ or ▼ buttons to select the correct mode then wait five seconds to accept your selection. -
Page 7: Setup Menu
COLD TANK °F °F 3) BACKUP 3) ROTATE TIME OUTDOOR °F 4) ENERGY CLOCK 4) ROT CYCLES 5) PRIORITY COLD 5) OFF STAGING BKUP REV VL 6) WIFI 6) °C OR °F °F © HBX Control Systems Inc. 2018 Page 5... -
Page 8: Geothermal Mode Programming
GEOTHERMAL MODE Multicolour backlit Display The Multicolour Backlit Display is one of the key features of the HBX Controls stand-alone ECO-0550 Control. Depending on which mode of operation is selected the screen color will change to indicate information about the status of the system. -
Page 9: Heat Pump Setup
If set to OFF the heat pumps will all stage off at the same time, based off of tank temperature and differential settings. (OFF/ON) Default: ON © HBX Control Systems Inc. 2018 Page 7... -
Page 10: Tank Setup
HOT TANK SETUP WITHOUT OUTDOOR RESET Warm Weather Shut Down HOT TANK SETUP HOT TANK SETUP This setting is used to set the temperature in which the ECO-0550 will go into WWSD. If HOT TANK SETUP 65°F 1) WWSD 65°F 1) WWSD the system rises above this temperature, the system will be shut off. - Page 11 HOT TANK SETUP WITH OUTDOOR RESET Warm Weather Shut Down HOT TANK SETUP This setting is used to set the temperature in which the ECO-0550 will go into WWSD. If 65°F 1) WWSD the system rises above this temperature, the system will be shut off. In WWSD the heat 11°F...
- Page 12 6) WIFI COLD TANK SETUP WITHOUT OUTDOOR RESET Cold Weather Shut Down COLD TANK SETUP This setting is used to set the temperature in which the ECO-0550 will go into CWSD. If 75°F 1) CWSD COLD TANK SETUP the system goes below this temperature, the system will be shut off. In CWSD the heat 2) OUTDOOR 75°F...
- Page 13 4) TANK TEMP Cold Weather Shut Down COLD TANK SETUP This setting is used to set the temperature in which the ECO-0550 will go into CWSD. 75°F 1) CWSD If the system goes below this temperature, the system will be shut off. In CWSD the 90°F...
-
Page 14: Backup Setup
H B X E C O - 0 5 5 0 G e o t h e r m a l C o n t r o l V e r s i o n 2 . 0 0 3) BACKUP SETUP Backup Setup SETUP MENU 2.00... -
Page 15: Ecoswitch Energy Clock
10AM 4) DOW 5) HOUR 10AM 5) HOUR 10AM 4) DOW 5) HOUR 10AM 6) MIN 5) HOUR 10AM 6) MIN 6) MIN 5) HOUR 10AM 6) MIN 6) MIN 6) MIN © HBX Control Systems Inc. 2018 Page 13... - Page 16 ENERGY CLOCK SETUP - WEEKDAY SETUP 3) WEEKDAY SETUP 4) WEEKEND SETUP Weekday Setup ENERGY CLOCK Adjust time and demand type options for weekday setup. The ECO-0550 is flexible 1) SET TIME 10:00 am and can be programmed for different schedules to run your heat pumps or backup 2) TIME ZONE MOUNTAIN...
-
Page 17: Priority Setup
SETUP MENU 2.00 1) HEAT PUMPS 2) TANKS (HOT/COLD) Default: COLD 3) BACKUP 4) ENERGY CLOCK 5) PRIORITY COLD 6) WIFI © HBX Control Systems Inc. 2018 Page 15... - Page 18 2.00 Wifi Setup 1) HEAT PUMPS SETUP MENU 2.00 2) TANKS This setting gives the user the capability to use the ECO-0550 remotely with the HBX 1) HEAT PUMPS SETUP MENU 3) BACKUP 2.00 2) TANKS ThermoLinx App. This setting displays the ECO-0550 password and Sync-Code. Enter...
-
Page 19: Wifi Setup
If you do not see the above description on the control you are not connected to a Wi-Fi network and will need to repeat the above process. 8. Now you are ready to add the ECO-0550 to your devices. See Adding Devices on page 19. © HBX Control Systems Inc. 2018... - Page 20 Network to configure your system. WiFi Setup --°F 9:41 AM 100% 1. After selecting “SETUP WIFI” on the ECO-0550 control, go into your smartphone settings and then go into your personal hotspot settings. Turn Add Name Here CHOOSE A NETWORK on your personal hotspot.
-
Page 21: Adding Devices
Adding thermostats to the HBX ThermoLinx App 1. On the home screen, select “+ Device”. SETUP WIFI 2. Add the name of your ECO-0550. Leave this option blank if the ECO-0550 itself is already displaying a name. 1) PASSWORD AB12 2) SETUP WIFI 3. -
Page 22: Sample Wiring And Diagrams
Outdoor 24 V AC System Pump HP 1 Backup Rev Valves 120 V AC NOTE: The THM-0200 Thermostat can be replaced with the HBX WiFi Zoning System. See ZON-0550 Installation Manual at hbxcontrols.com/resources.php ECO-0550 THM-0200 Outdoor Sensor 120 VAC Pump Relay... - Page 23 This is not an engineered drawing and does not necessarily include all the components for an entire system. It is intended ECO-0550 CONTROLLING 3 HEAT PUMPS WITH A SINGLE T as a representative sample of how the control may be wired for a sample application. It is the responsibility of the installer...
- Page 24 It is intended ECO-0550 CONTROLLING 2 HEAT PUMPS WITH DUAL TANKS AND BACKUP BOILER ve sample of how the control may be wired for a sample application. It is the responsibility of the installer...
-
Page 25: Troubleshooting Guide
• Check cold tank sensor is connected on pins (8-10) display • Check wiring on page 14 Outdoor Sensor displays dashes • Check outdoor sensor is connected on pins (9-10) on control display • Check wiring on page 14 © HBX Control Systems Inc. 2018 Page 23... - Page 26 • No heat/cool demand Reversing valve is not turning on • Check wiring on page 14 • Control is WWSD/CWSD For additional assistance with the ECO-0550, please contact our Technical Support Department toll free at: +1 (855) 410-2341 Page 24...
-
Page 27: Warranty Information
HBX Controls warrants each of its products to be free from defects in workmanship and materials under normal use and service for a period of 24 months from date of manufacture or 12 months from date of purchase from an HBX Authorized Dealer, if within the above documented period after date of manufacture. - Page 28 Phone: +1 (403) 720-0029 Fax: +1 (403) 720-0054 Email: inf o @ hbxcontrols.com Web: www.hbxcontrols.com Toll Free Technical Support: +1 (855) 410 2341 HBX Control Systems Inc. 4516 - 112 Avenue SE © HBX Control Systems Inc. 2018 Calgary, AB Canada T2C 2K2...
