Owner's Manual
EZBoilers
EZ-Classic and EZ-Pro
UL 2523-2009 Solid fuel fired hydronic heating appliances, water heaters, and boilers,
CAN/CSA B366.1-2011 Solid fuel fired central heating appliances.
EZBoilers
Formerly Ridgewood Stoves
1445 170th Ave.
Hersey, Michigan 49639
Call or text: (231) 823-2499
INTRODUCTION
Thank you for purchasing our stove. Developed and manufactured in Hersey Michigan,
the EZBoilers "Simple and Strong" stove has been designed to supply heat and hot
water for your home or business. The strongest structural design is round and the
weakest is square or rectangular. This pertains to stoves as well. For longevity and
strength, our stove uses a round, heavy-duty design for the firebox. Rectangular designs
with many overlapping welds and faceted corners can be problematic. Our water jacket

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EZ-Pro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EZBoilers EZ-Pro

Summary of Contents for EZBoilers EZ-Pro

  • Page 1 Thank you for purchasing our stove. Developed and manufactured in Hersey Michigan, the EZBoilers “Simple and Strong” stove has been designed to supply heat and hot water for your home or business. The strongest structural design is round and the weakest is square or rectangular.
  • Page 2 (231) 823-2499. We will be happy to answer any questions you have. Thanks again, The EZBoilers Simple and Strong Stove Team Simple and Strong….,that’s our Stove. SAFETY Do not operate this equipment for anything other than its intended purpose.

  • Page 3: Installation

    Never leave the stove unattended if the firebox door is open or unlatched. Do not touch any part of the front of your stove that is uninsulated. Temperatures can reach 200 degrees in these areas. Failure to do this could result in severe burns. To avoid electrical shock, disconnect the electricity before performing maintenance.
  • Page 4 W = 44 inches. EZ-Classic: L = 48 inches W = 44 inches Those measurements are from the outside of the legs, which are approximately 3 inches square. Therefore, the EZ-Pro measures 57″ by 41″ on center, and the EZ-Classic measures 45″ by 41″ on center.
  • Page 5 Grounding Rod A properly installed grounding system will protect people from electrical shock, help safeguard expensive electronic equipment, prevent electrolysis, limit neutral-to-ground voltage and satisfy the NEC along the way. Use only a 4GA or larger wire with proper grounding clips. Grind paint away where the wire attaches to the stove in order to get a solid electrical connection.
  • Page 6 Initial Water Fill-Up Attach a garden hose to the hose fitting on the return line pipe. Shut off the return line ball valve and fill the entire system until water runs out of the vent pipe on the top of the stove.

  • Page 7: Section 2 - Getting To Know Your Stove

    SECTION 2 – GETTING TO KNOW YOUR STOVE Stove Construction Firebox Our firebox is 5/16” thick, which gives us one of the thickest fireboxes available.The strongest structure is round and the weakest is square or rectangular. For longevity and strength, our firebox uses this round boiler design. Round designs have fewer welds; therefore, fewer spots for possible failure.
  • Page 8 Sight Glass A sight glass is a simple mechanical way to keep track of the water level in your stove. With a quick glance, you know that your stove has the correct amount of water. If you do not see water in the sight glass, water must be added to your stove. Commonly, the water level in the gauge will settle just below the halfway point.
  • Page 9 Boiler Vent The boiler vent is a port coming off of the highest part of the water jacket of the stove, and is used to vent air from the stove when it is filled. It is also used to prevent a vacuum from forming when the stove is drained.
  • Page 10 Diverter If you look at the top of the firebox, you will see a metal box. This box is called a Diverter. The diverter is mounted under the chimney. It is designed to push smoke and heat to the back of the stove so that the stove heat does not go straight out the chimney.

  • Page 11: Section 3 - Maintenance And Cleaning

    Your stove comes with one electrical box containing aquastat wiring. You or your electrician will probably add an additional box for your pump wiring. The stove is prewired and ready for 115 volts. Electronics Aquastat Controller The aquastat controller for your stove is designed for many heating and cooling and high temperature applications.
  • Page 12 Make sure your stove is full of water (SIGHT GLASS), run the pumps and check for leaks. Remember, the pump is lubricated with water. It is normal for water to overflow the first time you fire the stove and water expands. Once the stove finds its normal operating level, it is only necessary to note that level on the gauge, and only add water when the level drops significantly.

  • Page 13: Corrosion Control

    Install an anode rod. They are commonly used on water heaters to reduce rusting. They also work for outdoor boilers. On your Ezboilers stove, the anode rod can be connected through the drain port, which is the lowest port on the back of the stove. Simply add a tee fitting to that port, install the anode rod straight into the water jacket, and install your drain valve on the side of the tee.

  • Page 14: Water Maintenance

    Water Maintenance It is important that the water be drained every year and refilled with treatment and water, or as needed due to sludge and build up. Water treatment can be purchased from Wood Boiler Solutions. Their website is: outdoorwoodfurnaceparts.com/, or local customers can purchase it for $30 at our office in Hersey, Michigan.

  • Page 15: Ash Disposal

    Ash Disposal Ashes should be placed in a metal container with a tight-fitting lid. The closed container of ashes should be placed on a noncombustible surface, well away from all combustible materials. If the ashes are going to be buried in soil or otherwise locally dispersed, they should be left in the closed container until all cinders have thoroughly cooled.
  • Page 16 Then press and hold the ‘set’ button. It can take 10-20 seconds, but when it shows ‘0’ in the display, release the ‘set’ button. You are now in the programming mode. From here out in the instructions do not hold the buttons. Just a simple single push is all that is required.
  • Page 17 have found that setting it to 7 works very well. Pressing the ‘set’ button will lock the setting in and return you to the ‘r0’ display. ▲ Press the ‘ ’ up arrow button one time and ‘r1’ will display. This is not used and should remain at 0.

  • Page 18: Section 5 - Specifications

    ▼ To exit the programming mode press the ‘set’ button and the ‘ ’ down arrow at the same time. This will return you to displaying the current temperature. Quick Adjustment of the Run Temperature You can quickly adjust the run temperature by pressing the ‘set’ button once. The screen will say ‘SP’.

  • Page 19: Door Gasket

    Approximate Weight 1,800 lbs. The EZ-Pro model firebox size is 37” x 59” with a door size of 24” x 24” and the stove weighs around 1,800 pounds. The EZ-Pro is a good size for a large house or an average house plus garage.
  • Page 20 Our Part Door Rope Seal $3.00 per ft 1” standard fiberglass firedoor rope gasket. Glue in place with high temperature silicone adhesive. SOLENOID Our Part Solenoid $45.00 Grainger Part 4×420 Manufactured by Dormeyer Model 2005-M-1 SIGHT GLASS Our Part Sight Glass $75.00 Grainger Part 1U614 Model G901-4 Manufactured by LDI INDUSTRIES PUMPS...

  • Page 21: Thermocouple Probe

    Small Pump $125.00. Model GPD15-6SFC. Manufactured by Badger. Large Pump $250.00. Model GPD25-10SFC. Manufactured by Badger. PUMP FLANGE Our Part Flange Kit $50 Manufactured by Palconn Model 150SWP600WOG AQUASTAT CONTROLLER (Thermocouple temperature switch) Our Part Controller $125.00 Manufactured by Dwyer Instruments, Love Division. Model TCS-4010 THERMOCOUPLE PROBE...

  • Page 22: Heat Exchanger

    Our Part Thermocouple Probe $41.00 Model TCP60089 Manufactured by Temco. HEAT EXCHANGER Our Part Heat Exchanger $250.00 up to 22×22 SIDEARM HEAT EXCHANGER Our Part Sidearm with Mix Valve $250.00 PLATE EXCHANGER...

  • Page 23: Mixing Valve

    Our Part 20 Plate Exchanger $200.00 MIXING VALVE Our Part Mixing Value $150.00 INSULATED PEX PIPING Our Part 3 Wrap, $6.45 per foot 5 Wrap, $9.50 per foot...

  • Page 24: Limited Warranty

    Limited Warranty EZBoilers Models EZ-Classic and EZ-Pro Who is covered This limited warranty covers only the original purchaser of the product. The limited warranty is not transferable to subsequent owners or purchasers of this product. What is covered The stove has a one (1) year workmanship warranty.

  • Page 25: Limitation On Liability

    EZBoilers. Limitation on liability EZBoilers shall not be responsible for any incidental or consequential damages to persons or property. Please observe proper safety precautions at all times. Some countries, districts, or states do not allow the limitation or exclusion of relief, incidental, consequential, special, or indirect damages, or the limitation of liability to special amounts, so the above limitations or exclusions may not apply to you.
