  • Page 1 M1805 USER/INSTALLER MANUAL V4.0 REV. 10/2018...

  • Page 2: Table Of Contents

    00. CONTENT INDEX 01. SAFETY INSTRUCTIONS STANDARDS TO FOLLOW 02. CONNECTION SCHEMES COMPONENTS CONNECTION RADARS AND PROGRAM SELECTOR CONNECTION CONNECTION OF 2 SINGULAR DOORS WITH INTERLOCK DOOR WITH 2 LEAVES 03. THE AUTOMATION TECHNICAL CHARACTERISTICS 04. PRE-INSTALLATION WIDTH/WEIGHT RATIO INSTALLATION MEASURES | OPENING DIRECTION 05.

  • Page 3: Safety Instructions

    01. SAFETY INSTRUCTIONS 01. SAFETY INSTRUCTIONS STANDARDS TO FOLLOW STANDARDS TO FOLLOW • It is important for your safety that these instructions are followed. This product is certified in accordance with European • Keep these instructions in a safe place for future reference. Community (EC) safety standards.

  • Page 4: Connection Schemes

    Control board If you do not use photocells place a shunt between 11- 12 inputs. K1 K2 +24V Battery 24V 12-24V AC/DC M1805 Automatism M1601 M1601 Radar Radar Jumper N.C. Jumper N.O. CR10MS CR10MS FOTO9S1A Photocells (closure) FOTO9S1A Photocells (open) The electro lock current can not exceed 600mA.

  • Page 5: Radars And Program Selector Connection

    02. CONNECTION SCHEMES RADARS AND PROGRAM SELECTOR CONNECTION Control board K1 K2 black brown yellow white white green green EXTERNAL purple Radar M1601 orange PROGRAM SELECTOR brown yellow white green Control board INTERNAL Radar M1601 K1 K2...

  • Page 6: Connection Of 2 Singular Doors With Interlock

    02. CONNECTION SCHEMES CONNECTION OF 2 SINGULAR DOORS WITH INTERLOCK 1st door K1 K2 is closed Control board of the 1st door K1 K2 2nd door started opening Control board of the 2nd door Operation: When using 2 singular doors with interlocking, connected to each other, you should be aware these connections.

  • Page 7: Door With 2 Leaves

    02. CONNECTION SCHEMES DOOR WITH 2 LEAVES Operation: When using a door with two leaves, you should note these connections. This function will allow the two sheets work in a coordinated manner. Control board 1 Control board 2 M1601 Radar K1 K2 K1 K2 Leaf nº2...

  • Page 8: The Automation

    03. THE AUTOMATION 04. PRE-INSTALLATION TECHNICAL CHARACTERISTICS The M1805 is an automation with anodized aluminum chassis, developed to use in pedes- trian doors up to 100kg. OPTIONAL COMPONENTS KIT COMPONENTS (Not included in kit) • The control board is microprocessor controlled and does self programming. Users only need to select the speeds and the pause time.

  • Page 9: Installation Measures | Opening Direction 9A

    04. PRE-INSTALLATION 04. PRE-INSTALLATION INSTALLATION MEASURES | OPENING DIRECTION INSTALLATION MEASURES | OPENING DIRECTION Opening orientation: Opening direction: Opening orientation: Opening direction: LEFT INSIDE LEFT OUTSIDE = -30-+30 = -30-+30 Opening orientation: Opening direction: Opening orientation: Opening direction: RIGHT INSIDE RIGHT OUTSIDE = -30-+30...

  • Page 10: Installation

    05. INSTALLATION 05. INSTALLATION INSTALLATION PROCESS INSTALLATION PROCESS 01 • Remove the 4 screws from the sides of the 02 • Remove the 6 screws which hold the au- 07 • Apply automation in the fixing plate and 08 • Slide the automation to the right and se- automation and remove the cover.

  • Page 11: The Control Board

    06. THE CONTROL BOARD 06. THE CONTROL BOARD TECHNICAL CHARACTERISTICS TECHNICAL CHARACTERISTICS 6 •Two singular doors connection - Entrance Interlocking between 2 singular doors 7 • Two singular doors connection - Exit 152mm 8 • Common 9 • Photocells (Aperture) - Connection (N.O) of a safety sensor for the opening. If the terminal closes during the aperture, the door will stop opening and will start to close.

  • Page 12: Troubleshooting

    07. TROUBLESHOOTING INSTRUCTIONS FOR FINAL CONSUMERS INSTRUCTIONS FOR SPECIALIZED INSTALLERS Anomaly Procedure Behavior Procedure II Find source of the problem • Door/Motor • Make sure you have • Still not working • Consult a qualified 1 • Open the control board and check if it has a 230V power supply; doesn't work a 230V power supply MOTORLINE technician.
