BatteryMINDer
12 Volt 1500 mA
Charger - Maintainer - Desulfator
INCLUDES
:
•
Auto-Temp Compensation Sensor, installed
•
Optional Permanent Mounting Brackets and
screws
•
Battery Clips (Fully-Insulated 6 ft.,
Aircraft Grade, 15A replaceable fuse)
•
Ring Terminal Assembly with 15A replaceable
fuse
*
CAUTION:
• NOT FOR USE WITH AVIATION BATTERIES
• NOT FOR USE WITH LITHIUM TYPE BATTERIES; POTENTIAL FOR
EXPLOSION MAY EXIST IF USED
VDC Electronics, Inc. • 155 W. Carver St., Ste. 2 • Huntington, NY 11743
www.BatteryMINDers.com • techsupport@vdcelectronics.com
Rev. A-061015
READ AND SAVE THESE
INSTRUCTIONS
Tech Support: 800-379-5579 x6 (ET, M - F)
®
1215C
Convertible
*
P/N VDC1215C-MNL
Advertisement
Table of Contents
Related Manuals for BatteryMINDer 1215C
Summary of Contents for BatteryMINDer 1215C
- Page 1 BatteryMINDer ® 1215C Convertible 12 Volt 1500 mA Charger - Maintainer - Desulfator INCLUDES • Auto-Temp Compensation Sensor, installed • Optional Permanent Mounting Brackets and screws • Battery Clips (Fully-Insulated 6 ft., Aircraft Grade, 15A replaceable fuse) • Ring Terminal Assembly with 15A replaceable...
-
Page 2: Table Of Contents
MODEL FEATURES AND CALL-OUTS ............8 LED INDICATION TABLE ................9 START-UP OPERATING INSTRUCTIONS ..........10 CHARGING STAGES ................10 ADDITIONAL FEATURES ................. 10 ATTACHING BATTERYMINDER 1215C ........... 11 TROUBLESHOOTING ................12 MAINTAINING MULTIPLE BATTERIES ........... 12 VOLTAGE TABLE ..................12 CHARGING CURVE .................. 13 SAFETY &... -
Page 3: Required Safety Instructions
Model 1215C BatteryMINDer ® REQUIRED IMPORTANT SAFETY INSTRUCTIONS WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSON, OBSERVE THE FOLLOWING: 1. SAVE THESE INSTRUCTIONS 1. This manual contains important safety and operating instructions for BatteryMINDer1215C. 2. Do not expose charger to rain or snow. - Page 4 Model 1215C BatteryMINDer ® 6. Do not operate charger with damaged cord or plug – replace the cord or plug immediately. 7. Do not operate charger if it has received a sharp blow, been dropped, or otherwise damaged in any way; call VDC Electronics Tech Support Dept.
-
Page 5: Preparing To Charge
Model 1215C BatteryMINDer ® 19. Be extra cautious to reduce risk of dropping a metal tool onto battery. It might spark or short-circuit battery or other electrical part that may cause explosion. 20. Remove personal metal items such as rings, bracelets, necklaces, and watches when working with a lead-acid battery. -
Page 6: Dc Connection Precautions
Model 1215C BatteryMINDer ® from battery will corrode and damage charger. 33. Never allow battery acid to drip on charger when reading electrolyte specific gravity or filling battery. 34. Do not operate charger in a closed-in area or restrict ventilation in any way. - Page 7 Model 1215C BatteryMINDer ® block away from battery. Do not connect clip to carburetor, fuel lines, or sheet-metal body parts. Connect to a heavy gage metal part of the frame or engine block. 47. When disconnecting charger, turn switches to off, disconnect AC cord, remove clip from vehicle chassis, and then remove clip from battery terminal.
-
Page 8: Model Features And Call-Outs
Model 1215C BatteryMINDer ® Model 1215C Call-Outs FEATURES LED Indicators (see expanded views on page 8) A.C. Input plug ATS-1 Ambient Temperature Sensor Temperature Sensor input connector Output cord with quick connect plug (tethered cap not shown) Fully Insulated Battery Clip cord set (Aircraft-Grade) with 15A... -
Page 9: Led Indication Table
Model 1215C BatteryMINDer ® Expanded View of 1215C Unit Label TABLE 2 CHARGING DESULFATING POWER LED INDICATIONS MAINTAINING LOW BATTERY FAULT BLUE GREEN LED Color GREEN YELLOW AC Power connected, Battery disconnected AC Power connected, battery disconnected >10 sec., charger in... -
Page 10: Start-Up Operating Instructions
1. Place the negative (BLACK) connection on the negative battery terminal. 2. Place the positive (RED) connection on the positive battery terminal. 3. Plug in the BatteryMINDer. 4. Charging will be GREEN (flashing) (see item #5 in Table 2.) Reverse leads if you do not see this. -
Page 11: Attaching Batteryminder 1215C
Model 1215C BatteryMINDer ® Attaching BatteryMINDer 1215C NOTE: When not connected to an electrical source and while attached to the bracket under the hood and to your car battery (fig. 1, 2, 3 & 4), the BatteryMINDer does not provide power to nor draw power from your vehicle. -
Page 12: Troubleshooting
If connecting 2 batteries of half your unit’s voltage (example: 6V batteries on a 12V unit), wire them in series (BatteryMINDer positive to positive A, negative A to positive B, negative B to BatteryMINDer negative). When wired in series they act as one large system at the combined voltage (example: 6V+ 6V = 12V). -
Page 13: Charging Curve
Model 1215C BatteryMINDer ® Charging Curve Rev. A-061015 Page 13 P/N VDC1215C-MNL... -
Page 14: Safety & Protection
Model 1215C BatteryMINDer ® Safety & Protection Complies with the requirements of the Safety standards: Standard(s) for Battery Chargers (UL-1236) EMC standard: FCC part-15 Input-Output 1240Vac 50Hz with 1 minute, 5mA ac insulation test: Cooling: By natural cooling Specifications including Electrical Cable & Physical Parameters BatteryMINDer 1215C 12VDC @ 1.5A... -
Page 15: For Repair Or Replacement
Model 1215C BatteryMINDer ® FOR REPAIR OR REPLACEMENT All returns must be authorized by VDC Electronics. In the event that you believe your product may be defective, you MUST speak to a VDC Electronics technician at 1-800-379-5579 x6 (ET) before proceeding further. -
Page 16: Guarantee
Replacement” section of this manual for additional information. BatteryMINDer One-Year 100% Unconditional Money-Back GUARANTEE This BatteryMINDer product is guaranteed to perform as claimed or WE will refund your full purchase price, including all taxes, shipping or handling cost applicable to the purchase.
