- Page 2 SEI INDUSTRIES LTD. 7400 Wilson Avenue Delta, B.C. Canada V4G 1E5 Phone: (604) 946-3131 Fax: (604) 940-9566 E-Mail: seisales@sei-ind.com Website: www.sei-ind.com COPYRIGHT © 2008 SEI INDUSTRIES LTD. ALL RIGHTS RESERVED PRINTED IN CANADA We Engineer Solutions RainDrain Operations Manual (Version D)
-
Page 3: Table Of Contents
Table of Contents Section 1: Introduction to the RainDrain System Overview ........................1 Performance ....................1 Section 2: Installation Overview ........................3 Drain Installation ......................4 Filtration System ......................6 Filtration Unit Installation ................6 Section 3: Operations Operational Procedures ....................8 Section 4: Maintenance and Troubleshooting Maintenance .........................9... -
Page 4: Section 1: Introduction To The Raindrain System
18" Filter Assembly Performance The RainDrain system allows rainfall and water from other sources to be discharged from the berm. The filtration unit stops all target contaminates, acting as a hydrocarbon selection unit and reducing the dis- charged water below 10 ppm hydrocarbon content. - Page 5 It is still possible that a small amount of fuel will escape through the RainDrain because of the higher fuel to water discharge ratio. This discharge can be trapped in a small discharge pit filled with hydrocarbon absorbent pads.
-
Page 6: Section 2: Installation
Overview Section 2: Installation Section 2: Installation Overview We Engineer Solutions RainDrain Operations Manual (Version D) -
Page 7: Drain Installation
Drain Installation To install a RainDrain, the existing berm must be equipped with a drain. If your berm already has a drain, please see the information on Filtration Unit Installation. If no drain is present, or if the drain is not at a low point, a bulkhead fitting can be installed. - Page 8 Drain Installation Section 2: Installation Attach locking nut and tighten firmly. The installed fitting should now look like this. We Engineer Solutions RainDrain Operations Manual (Version D)
-
Page 9: Filtration System
The filtration unit must be assembled in the following order, beginning at the berm’s bulkhead fitting: Remove the ¾" (19 mm) plug and install the ¾" (19 mm) close nipple into the bulkhead. Attach the valve and sight glass assembly to the ¾" nipple in the bulkhead. We Engineer Solutions RainDrain Operations Manual (Version D) - Page 10 Filtration System Section 2: Installation Attach the black hose and filtration canister to the sight glass assembly. Install the leaf guard on the inside of the berm. Leaf guard installed inside the berm. We Engineer Solutions RainDrain Operations Manual (Version D)
-
Page 11: Section 3: Operations
If the filter inlet is higher than the base of the berm, the discharge flow will be reduced. Valve in closed position. Valve in open position. We Engineer Solutions RainDrain Operations Manual (Version D) -
Page 12: Section 4: Maintenance And Troubleshooting
Section 4: Maintenance and Troubleshooting Maintenance Filter Cartridge Replacement Close the valve. Valve in closed position. Remove the camlock fitting using a slot screw- driver to loosen the clamp and then remove the cap. We Engineer Solutions RainDrain Operations Manual (Version D) - Page 13 Place the cap over the inlet end of the new car- tridge. Then, attach the female camlock and slide the cartridge into the canister. Push the cap into place. Replace the cap and tighten the hose clamp. We Engineer Solutions RainDrain Operations Manual (Version D)
-
Page 14: Troubleshooting
Turn the valve to the ON position. The system is now ready to operate. Valve in open position. Troubleshooting If the RainDrain system does not work and/or if no water is being discharged: • Check for kinks in the hose or in the sight glass. •... -
Page 15: Section 5: Converting The Raindrain System
Upgrading to the New Canister Model Section 5: Converting the RainDrain System Section 5: Converting the RainDrain System Upgrading to the New Canister Model Loosen the hose clamp and remove the cap. Pour the contents into a liquid tight container. - Page 16 Upgrading to the New Canister Model Section 5: Converting the RainDrain System Place the tube and the bulkhead fitting into the container. Slide the new filter cartridge into the canister. Tighten the hose clamp and attach the female cam- lock.
-
Page 17: Section 6: Specifications And Parts
• Alaska State AAC-75.075 The RainDrain is designed to produce a discharge of water that does not contain more then 10mg/L of free oil and grease as measured by the partition-gravimetric method. Independent testing has proven the Rain- Drain exceeds this performance requirement and those results are available upon request. -
Page 18: Parts List
Parts List Section 6: Specifications and Parts Parts List 36" RainDrain Parts ITEM PART DESCRIPTION QTY. NUMBER IBMPH0758 HOSE, OIL DRAIN ¾” X 8’ PLA075C NIPPLE ¾” CLOSE ALUMINUM IBMPS075 STRAINER LEAF ¾” C/W ¾”CLOSE NIPPLE IBMPH075S SIGHT GLASS ASSEMBLY C/W VALVE IBRDC36 CARTRIDGE FILTER RAIN DRAIN 36”... -
Page 19: 18" Raindrain Parts
Parts List Section 6: Specifications and Parts 18" RainDrain Parts ITEM PART DESCRIPTION QTY. NUMBER IBMPH0758 HOSE, OIL DRAIN ¾” X 8’ PLA075C NIPPLE ¾” CLOSE ALUMINUM IBMPS075 STRAINER LEAF ¾” C/W ¾”CLOSE NIPPLE IBMPH075S SIGHT GLASS ASSEMBLY C/W VALVE IBRDC18 CARTRIDGE FILTER RAIN DRAIN 18”... -
Page 20: Section 7: Warranty
There are no implied warranties nor is there any warranty that can be assumed from any representation of any person, except the company itself. Exclusions This warranty is void if the product is not assembled, used and/or maintained in accordance with the oper- ator’s manual supplied by SEI. We Engineer Solutions RainDrain Operations Manual (Version D)
