Summary of Contents for Securimax Smart-Vent
- Page 1 ...the SMART way to Ventilate your Home User Guide...
- Page 2 Introducing your Digital Control Panel 12x2 LCD Display with Backlight Mode Button On/Off Button Enters into the setup menu Change Filter LED LED will illuminate Up/Down Arrows when the filter Use the arrows to needs changing scroll through the menus Reset Button This will reset the system to the Select Button factory settings Confirms the menu...
-
Page 3: Table Of Contents
Contents 1. General Information .......... 1 How The Smart-Vent System Works ........ 1 Smart-Vent Product Range ........... 1 Control Panel Maintenance .......... 1 Smart-Vent Support ............ 1 2. Getting Started ............ 2 On/Off Button .............. 2 3. Operating Mode ............ 3 4. Setup Mode ............ 4 Setup Mode Menu ............. 4 5. Setup Functions ............ 5 System Fan Speed ............. 5 System Maximum Temperature .......... 6 System Minimum Temperature .......... 7 Filter Status .............. 8 Heater Option .............. 9 Heater Mode .............. 10 Override Heater Mode ............ 10 Timer Mode .............. 12 Customer Service ............ 14 Set Real Time Clock ............ 15... -
Page 4: General Information
With an easy-to- the room temperature for the consumers follow menu you can simply relax while benefit. your Smart-Vent system is hard at work providing a healthy comfortable living environment for you and your family. Smart-Vent Product Range There are several Smart-Vent product •... -
Page 5: Getting Started
2. Getting Started On/Off Button This button turns the Smart- Smart-Vent Vent controller ON and OFF. Active When the Smart-Vent is off the display shows either: Smart-Vent Software Version 2.XX EcoSmart-Vent Ceiling= 22 Room= 23 This is dependent on the model purchased. If the model purchased includes a summer function then the controller will state “Smart-Vent”. -
Page 6: Operating Mode
Fan3x Note: The display illuminates on the first press of a button, but no action is taken In this example, the Smart-Vent air is until the second press of any button. drawing from the ceiling cavity, the heater is disabled and the fan is operating at After 15 seconds if the maximum speed. -
Page 7: Setup Mode
4. Setup Mode System Fan Speed Setup Mode is designed to allow the householder to customise the Smart-Vent operational parameters to their individual System requirements. Max Temp For example the householder may have preferences for the normal fan speed and the minimum temperature setting for... -
Page 8: Setup Functions
To select any of the settings press SELECT button. System Fan Speed SELECT The Smart-Vent controller uses a 2 or 3 * Setup Heater Mode option is displayed speed motor to control the flow of filtered only if the heater is installed and Enabled in air into the house. -
Page 9: System Maximum Temperature
Once SELECT is pressed the display returns System to Setup Mode Fan Speed System Fan Speed Either press MODE or wait for 15 second SELECT timeout to return to Operational Mode. The display will indicate the current Fan speed for example: Speed 2: MODE Fan Speed Ceiling= 24... -
Page 10: System Minimum Temperature
To change or check the value of the System minimum temperature enter the Setup Mode Max. Temp as follows: MODE SELECT Max. Temp (Press x3) = 31 System Min. Temp Use the buttons to increase or decrease the maximum temperature setting. SELECT Note: To activate this change in the maximum temperature setting you must... -
Page 11: Filter Status
(09) 259 1662 to be Timer? No directed to your nearest outlet to purchase a replacement filter. Use the buttons to toggle The Smart-Vent controller flashes the between yes and no. ‘change filter’ light on the control panel when the filter is full. -
Page 12: Heater Option
Reset Filter Timer page is removed until the filter is full again. The timer calculates % usage of the filter SELECT based on the fan speed. A Smart-Vent system operating on low speed will take Heater is now enabled in Normal Mode. approx 1... -
Page 13: Heater Mode
In the Operating Mode the screens will show • Override Mode, where the householder as follows: can force the heater ON for a certain time period irrespective of the ceiling Ceiling Vent temperature and minimum temperature Heat Fan3x setting. • Timer Mode, where one or two time Normal periods can be set by the householder Operation... - Page 14 Enter Setup mode and step through to SELECT Heater Mode. Select Override Mode and set the heater for 1 hour: SELECT Smart-Vent will turn ON the heater at MODE fan speed 2 when the controller returns to Operational Mode. Screen three in Operational Mode will display:...
-
Page 15: Timer Mode
(9pm-7am) householder can set certain times when the Timer Mode - Time settings that the Smart-Vent heater can be active. Normally heater will operate if the ceiling the heater will come on and go off under the temperature is below the minimum... - Page 16 space is above the minimum temperature setting the heater will not come on until The minutes flash. Use the the temperature drops below the minimum buttons to set the minutes. Press Select: level. (In this instance 9pm) To enter Timer Mode, ensure the heater is SELECT enabled and go to the Setup Mode Set OFF Time...
-
Page 17: Customer Service
Set the hours and minutes as for the ON Customer Service time and press SELECT to exit the mode. To assist with any questions you may have regarding your Smart-Vent controller a contact number is conveniently stored in setup mode. SELECT... -
Page 18: Set Real Time Clock
Then the seconds will blink. Set Real Time Clock The Smart-Vent controller has a real time Use the buttons to set the clock, one to display the time but essentially correct seconds, then press SELECT: to allow the householder to set the times the heater is active. -
Page 19: Fan Mode
Note: Fan Mode 1) In a power cut situation an on-board Note: Only applies to Eco Smart-Vent battery keeps the clock operational models (SV01, SV02, SV04 & SV06). 2) The setting of the clock is done in 24hr Does not apply to Summer-Vent models format but for readability the clock that (SV02S, SV04S & SV06S). is displayed on screen two of Operational... - Page 20 If this Fan Mode is active and the maximum Fan Mode temperature threshold has been exceeded Normal then the Normal Operating Mode shows the fan icon as stationary & no fan speed number. Ceiling Vent Heat Fan x Fan Mode Max Temp off The fan icon will return to a rotating display when the ceiling temperature falls below...
-
Page 21: Keypad Lock Function
6. Keypad Lock Function Normal Operation is then restored and the At times it is useful to ‘lock’ the keypad so padlock icon vanishes. that those little fingers or even bigger ones don’t reconfigure your setup codes. To prevent the keys from being accidentally pressed, press and hold SELECT until the controller beeps x4 SELECT... -
Page 22: Reset Function
Reset System Active If a system reset is not required, press SELECT Ceiling= 24 Room= 20 SELECT System will return operation to Normal Note: Mode RESET does not function when Smart-Vent is in the OFF mode Ceiling= 24 Smart-Vent Room= 20... -
Page 23: Error Functions
8. Error Functions The Smart-Vent system monitors the communications and performance of the system. If the Smart-Vent controller can not communicate with the ceiling unit the operational display flashes the error message every 5 seconds: Error #1 No Comms If the temperature sensor in the ceiling... - Page 24 Customer Support Telephone (09) 259 1662 Facsimile: (09) 259 1661 S E C U R I M A X L I M I T E D Email: sales@securimax.co.nz Website: www.smartvent.co.nz PUB0225 iss:03 06/07...
