NPower SmartPower Quick Start Manual

(with mains adaptor) (with 3 x AA batteries)
npower Home Energy Monitor guide (Booklet)

LOCATE LIVE FEED WIRE ON ELECTRICITY METER

SINGLE TARIFF METER: Identify the feed cable (cable 4) on your electricity
meter. This should be the last cable on the right if looking face onto the meter
(diagram 1).
DUAL TARIFF METER: Dual tariff meters (like Economy 7) will often have an
auxillary cable running between Cable 3 and Cable 4 (diagram 2). The feed
cable (Cable 4) is the live cable exiting from the meter. Clip the sensor to
Cable 4 (Cable 4 will always be on the right hand side of the meter).
SINGLE
TARIFF
DIAGRAM 1 DIAGRAM 2
Push open the cap to release the sensor. Place sensor around the feed cable
and push shut. You will hear it "Click" when closed securely.
There are two ways to power the display. The DC adaptor (recommended)
or batteries.
DUAL
TARIFF

SET UP THE TRANSMITTER

Mount transmitter near meter with Velcro pads provided. The transmitter has a
power supply already inside the unit.
Push and hold the Link button located on the back of the display unit (diagram 1)
for 2 seconds. The Transmission signal on the display will flash for one minute.
During the flashing period, press the button located on the transmitter
to complete synchronization.
When the link is completed you will see the transmission signal symbol
become solid.
If the link is not completed you will see dashes on the display. Repeat Step 5,
or refer to USER GUIDE
HOLD
2 SECS
THEN...
DIAGRAM 1 DIAGRAM 2
