Item #1000-050-439
Model #VWD1066BLS-1-HDU
High Efficiency Bottom Load
High Efficiency Bottom Load
Water Dispenser
Water Dispenser
Use & Care Guide
Use & Care Guide
Questions, problems, missing parts?
Before returning to the store,
call Glacier Bay Customer Service
8 a.m. - 6 p.m., EST, Monday - Friday
PLEASE READ THIS MANUAL
THOROUGHLY BEFORE USING THE
APPLIANCE AND KEEP THIS MANUAL
FOR FUTURE REFERENCE
THANK YOU
We appreciate the trust and confidence you have placed in Glacier
Bay through the purchase of this water dispenser. We strive to
continually create quality products designed to enhance your home.
Visit us online to see our full line of products available for your
home improvement needs. Thank you for choosing Glacier Bay!
180531
Advertisement
Table of Contents
Related Manuals for Glacier bay VWD1066BLS-1-HDU
Summary of Contents for Glacier bay VWD1066BLS-1-HDU
- Page 1 Bay through the purchase of this water dispenser. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Glacier Bay! 180531...
-
Page 2: Safety Information
Safety Information Warning: Never put anything flammable close to the dispenser Warning: This water dispenser is designed for indoor applications only. Warning: Do not damage the refrigeration cooling system. Warning: This Product can expose you to chemicals including Diisononyl phthalate (DINP) which is known to the State of California to cause cancer and Di-isodecyl phthalates (DIDP) which is known to the State of California to cause developmental harm. -
Page 3: Pre-Operation
Pre-Operation GROUNDING PRECAUTIONS SPECIFICATIONS Model No. VWD1066BLS-1-HDU Dimensions W x D x H 14.3 in. x 12.5 in. x 40.7 in. • 36.4cm x 31.8cm x 103.4cm Net Weight / Gross Weight 39.0 lbs / 45.4 lbs • 17,7 kg / 20,6 kg Heating Temp (approx.). -
Page 4: Warranty
Warranty Do not return this product to the store: Please contact Customer Service at 1-877-527-0313. The supplier warrants your water dispenser to be free from manufacturing defects in workmanship or material under normal operating conditions for one (1) year from the original date of purchase. This warranty applies only in the country in which it is sold and is available to the original purchaser only. - Page 5 Warranty The manufacturer does not assume or authorize any person to assume any obligations of liability in connection with this water dispenser. In no event will the manufacturer be liable for indirect, special, or consequential damages (including, without limitation, economic loss) or for any delay in the performance of this agreement due to causes beyond its control.
- Page 6 Pre-Operation (continued) PACKAGE CONTENTS Part Description Part Description Control Panel Door switch / Water pump operation control Kettle feature ON/OFF Button Adjustable cold water thermostat Ready-to-dispense indicator lights Carry handle Child resistant safety switch Drain valve Hot water dispensing button Condenser Coil Room temperature water Door magnets...
- Page 7 Pre-Operation (continued) INITIAL PRODUCT CLEANING PROCEDURE Water Dispenser Cleaner (50ml / 1.7oz) Hot Water (2L / 0.5 gal) Fresh Hot Water Repeat Steps 4 - 18 Note: INSTALLING THE WATER BOTTLE The stainless steel cap and handle is not available on all models.
-
Page 8: Operation
READY-TO-DISPENSE INDICATOR LIGHTS FLASHING Heater (hot water tank) is operational STEADY ON The hot water has reached optimum temperature and is ready for dispensing Hot water tank heating system is off, however water within the tank may still be very hot, always exercise caution when dispensing and/ or draining water from the hot water tank STEADY ON... -
Page 9: Care And Cleaning
3. DISPENSING HOT WATER Important: Your Vitapur® water dispenser is designed with a special safety feature (low water level sensor) that controls activation/operation of the Kettle Feature hot water tank heating system. If no water is present and/or low water levels are detected inside the internal water reservoir, activation/operation of the Kettle Feature hot water heating system is not possible. - Page 10 DRAINING THE RESERVOIRS GOING AWAY ON VACATION When not using the dispenser for long periods of time or when going on vacation, con- serve energy, unplug the dispenser and drain the reservoirs (see Draining the Reservoirs). Follow Initial Product Cleaning Procedures upon return and startup of the dispenser. DRINKING STRAW INSTRUCTIONS 3 Gal.
-
Page 11: Troubleshooting
Troubleshooting Problem Possible Cause Suggested Solution Water dispenser Drain cap and silicone seal are not Ensure seal is secure in drain plug is leaking secure. and tighten drain cap. Water is not hot All the water in the tank has been Replace with full bottle and wait;... - Page 12 Y CONSÉRVELO PARA FUTURA REFERENCIA GRACIAS Agradecemos la confianza que ha depositado en Glacier Bay a través de la compra de este enfriador de agua. Nos esforzamos continuamente por crear productos de calidad diseñados para mejorar su hogar. Visítenos en línea para ver nuestra línea completa de productos disponibles para sus...
-
Page 13: Información De Seguridad
Información de seguridad Advertencia: Nunca ponga nada inflamable cerca del dosificador. Advertencia: Este dispensador de agua esta diseñado para uso en interiores solamente. Advertencia: No dañar el sistema de refrigeración. Advertencia: Este producto puede exponerlo a usted a agentes químicos incluyendo ftalato de diisononilo (DINP), reconocido por el estado de California como causante de cáncer, así... -
Page 14: Pre-Operación
Pre-Operación PRECAUCIONES DE PUESTA A TIERRA ESPECIFICACIONES Modelo VWD1066BLS-1-HDU Dimensiones A x P x A 14.3 in. x 12.5 in. x 40.7 in. • 36.4cm x 31.8cm x 103.4cm Peso Neto / Peso Bruto 39.0 lbs / 45.4 lbs • 17,7 kg / 20,6 kg Temperatura de 194 ºF / 90 ºC... - Page 15 Garantía No devuelva este producto a la tienda : Por favor contacte Servicio al Cliente al 1-877-527-0313. El proveedor garantiza que su dispensador de agua está libre de defectos de fabricación en materiales o mano de obra bajo condiciones de uso normales durante un (1) año a partir de la fecha original de compra.
- Page 16 Garantía Excepto como se establece en este documento o requerido por la ley, el fabricante no hace ninguna otra garantía o acuerdo, expresa, implícita o legal incluyendo cualquier garantía implícita de comerciabilidad o aptitud para un propósito en particular. El fabricante no asume ni autoriza a nadie a asumir ninguna obligación de responsabilidad en relación con este dispensador de agua.
- Page 17 Pre-Operación (continuación) CONTENIDO DEL PAQUETE Parte Descripción Cant. Parte Descripción Cant. Panel de control Grifos dispensadores de agua Botón de activación de la función de Tetera Varilla de acero inoxidable Luces indicadoras Interruptor de la puerta / Listo-para-dispensar Controla el funcionamiento de la bomba de agua Dispositivo de seguridad Termostato ajustable para...
- Page 18 Pre-Operación (continuación) PROCEDIMIENTO INICIAL DE LIMPIEZA DEL PRODUCTO Solucion de limpieza del dispensador (50ml / 1.7oz) Agua Caliente (2L / 0,5gal) agua caliente fresca 2L repita los pasos 4 - 18 CÓMO INSTALAR EL Nota: La tapa y la manija de acero inoxidable, BOTELLÓN DE AGUA no está...
-
Page 19: Operación
LUCES INDICADORAS LISTO-PARA-DISPENSAR Intermitente Calentador (tanque de agua caliente) está en funcionamiento Encendida El agua caliente ha alcanzado la temperatura permanente óptima y está lista para dispensar ROJA Apagada El sistema de agua caliente está apagado, sin embargo el agua dentro del tanque todavía puede estar muy caliente, siempre tenga cuidado cuando dispense o drene el agua del depósito de agua caliente... -
Page 20: Cuidado Y Limpieza
3. CÓMO SURTIR AGUA CALIENTE Importante: Su expendedor de agua Vitapur® está diseñado con una función especial de seguridad (mecanismo de interruptor de flotación) que controla la activación y/o el funcionamiento del sistema calentador del tanque de agua caliente “Kettle”. Si no se detecta presencia de agua y/o su nivel está... - Page 21 DESAGÜE DE LOS DEPÓSITOS SI SALE DE VACACIONES Cuando no use el dosificador por períodos de tiempo prolongados o cuando esté de vacaciones, conserve la energía, desenchufe el dosificador y vacíe los depósitos (vea Desagüe de los depósitos). Cuando regrese, siga los procedimientos de limpieza y puesta en marcha inicial del dosificador.
- Page 22 CONSEJOS DE LOCALIZACIÓN Y REPARACIÓN DE AVERÍAS Problema Causa Posible Solución Sugerida El dosificador La tapa del desagüe y el sello Asegúrese de que el sello de la tapa del de agua está de silicona no están bien desagüe está bien asegurado y apriete la tapa goteando asegurados.
