HACH LANGE PROGNOSYS User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

DOC023.52.90351
PROGNOSYS
05/2014, Edition 7
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PROGNOSYS and is the answer not in the manual?

Questions and answers

Summary of Contents for HACH LANGE PROGNOSYS

  • Page 1 DOC023.52.90351 PROGNOSYS 05/2014, Edition 7 User Manual...

  • Page 3: Table Of Contents

    Use of hazard information ..................3 Precautionary labels .....................3 Product overview ......................4 Product components ....................4 Installation ........................4 PROGNOSYS communication card ................4 Install the RTC/PROGNOSYS communication card ............ 4 User interface and navigation ................4 Keypad description ......................4 Startup ..........................5 Add a sensor ........................ 5 Sort the sensors (RTC modules only) ..............
  • Page 4 Table of Contents...

  • Page 5: General Information

    General information In no event will the manufacturer be liable for direct, indirect, special, incidental or consequential damages resulting from any defect or omission in this manual. The manufacturer reserves the right to make changes in this manual and the products it describes at any time, without notice or obligation. Revised editions are found on the manufacturer’s website.

  • Page 6: Product Overview

    Make sure that all components have been received. If any items are missing or damaged, contact the manufacturer or a sales representative immediately. PROGNOSYS can only be used with an sc1000 controller that has an RTC communication card or a PROGNOSYS card installed. The PROGNOSYS files for the different sc sensors are kept on the sc1000 controller.

  • Page 7: Startup

    Note: PROGNOSYS is not available for all sensors. Only newer sensor models can use the PROGNOSYS function. Note: Make sure that an RTC or a PROGNOSYS communication card is installed in the sc1000 sensor module. When an RTC or PROGNOSYS communication card is installed, PROGNOSYS files are available for different sc sensors.

  • Page 8: Sort The Sensors (Rtc Modules Only)

    Figure 2 Add sensors 1 Select sensor 4 Add 2 Accept 5 Select additional sensor 3 Sensor list Sort the sensors (RTC modules only) The sensor sequence is programmed in the RTC module for the measurement values. To sort the sensors in the order specified for the RTC module, move the selected sensor with the UP and DOWN arrows.

  • Page 9: Delete A Sensor From The List

    Operation PROGNOSYS indicator bars If PROGNOSYS is installed, two additional horizontal bars show in the top right-hand corner of the measurement screen. The top bar is the measurement value indicator. The bottom bar is the service indicator. If no bars show up, refer to Troubleshooting on page 17.

  • Page 10: Display Description

    Set the countdown period between 7 and 14 days. The measurement value is invalid or immediately complete a service task. Blank (background No data is available or the RTC/PROGNOSYS communication card was removed. color) Display description The measurement value indicator is not a linear degrading indicator because of the sensor special model based calculation.

  • Page 11: Measurement Value Indicator

    Figure 6 Display overview for four sensors 1 Sensor 1 3 Sensor 3 2 Sensor 2 4 Sensor 4 Measurement value indicator If the sensor condition changes, the measurement value indicator changes. A deterioration of the measurement value indicator level in the top bar can change the color in the bottom service bar. Pending maintenance tasks do not have an immediate effect on the measurement value indicator (e.g., to replace the reagents).

  • Page 12: Configure The General Settings

    PROGNOSYS. The setting specifies the duration of the yellow maintenance countdown phase in days. For maintenance tasks that are not often necessary, the user can extend the yellow phase to operate on a self-sufficient basis.

  • Page 13: Configure The Sensor

    Configure the sensor Use the PROGNOSYS menu to monitor specific settings or to change the blink mode. 1. Push MAIN MENU>RTC MODULES/PROGNOSYS>PROGNOSYS. 2. Select the applicable sensor. 3. Select an option. Option Description MEAS. INDICATOR Shows the measurement indicator bar in %.
  • Page 14 Message Possible cause Solution Pump piston If 0 day is shown, the time for the • Contact technical support immediately to replace the replacement pump piston is expired. pump piston, so that the instrument operates correctly. • Set the counter when the pump piston is replaced. Air filters clean The maintenance for the air filter •...

  • Page 15: Nitratax Plus Sc

    NITRATAX plus sc Message Possible cause Solution Sensor, The signal level is too low. The sensor • Clean sensor window fully. Application possibly has a dirty window. The selected • Examine the wiper. check path length is too long (if applicable). The •...
  • Page 16 Message Possible cause Solution RFID-Data not valid The RFID calibration data for Enter the sensor code for the temporary sensor the cartridge could not be operation manually, then replace the cartridge. read. Reference potential The data supplied by the Examine the measurement values and if necessary, uncertain reference system for the replace the cartridge.

  • Page 17: Solitax Sc

    Message Possible cause Solution NH4 electrode The NH electrode is • Replace the cartridge. damaged damaged. • Examine if the cartridge was in contact (through vibrations) with the wall or other objects. NO3 electrode The NO electrode is damaged damaged. •...

  • Page 18: Ldo Probe, Model 2

    Message Possible cause Solution Check wiper The wiper is mechanically blocked. The • Examine and clean the measurement function measurement window is not clean anymore. window fully. No sample is pulled in the instrument. The • Complete a wiper test and do a stop Wiper position wiper is possibly in front of the window.

  • Page 19: Troubleshooting

    The factory calibration is not complete. Contact technical support. Troubleshooting Problem Possible cause Solution The sensor is selected Make sure that the RTC/PROGNOSYS communication card is from the RTC RTC/PROGNOSYS installed correctly. Select MAIN MENU>RTC communication card, but communication card MODULES/PROGNOSYS>PROGNOSYS>ALLOCATION no bars are shown.

  • Page 20: Replacement Parts

    PROGNOSYS register Table 4 shows PROGNOSYS parameters that are available from the RTC/PROGNOSYS communication card. These parameters can be sent to a superordinate programmable open loop control or to a computer via a fieldbus card such as Profibus or Modbus TCP/IP.
  • Page 21 Refer to the applicable fieldbus card documentation for information on the installation and configuration. Table 4 PROGNOSYS register Tag name Contents Modbus register Data Length PrognosysMeasIndicator1 MEAS INDICAT 1 40171 Unsigned Integer PrognosysServiceStat1 SERVICE STAT 1 40172 Unsigned Integer PrognosysMeasIndicator2...
  • Page 22 20 English...

  • Page 23: Index

    Index Bar color code ..........8 Bar indicator, Bar color code ......7 PROGNOSYS communication card ....4 Blink mode ............11 Communication card ........4 RTC communication card ......... 4 Measurement value indicator ......9 Service indicator ..........9...
