INSTRUCTION
MANUAL
MODEL: SA493

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SA493 and is the answer not in the manual?

Questions and answers

Gary
January 17, 2025

How to lubricate the motor bearing ( with/without dis-assembly ) ?

Summary of Contents for Samaire SA493

  • Page 1 INSTRUCTION MANUAL MODEL: SA493...
  • Page 2 Parts & Accessories- SA493 Item 1. Canopy 2. Downrod Assembly 3. Coupling Cover 4. Motor Assembly 5. Blades 6. Light kit 7. Light kit cover Canopy Downrod Coupling Cover Motor Assembly Blade Connect Plate Light Kit Plate Light Kit Cover...
  • Page 3: Table Of Contents

    SA493 Ceiling Fan DESCRIPTION Mounting Bracket Ball Canopy Downrod Coupling Cover Screw and Washers R Pin Lock Pin Screw Bracket Screw R Pin Screw and Washers Lock Pin Screw and Washers Metal Plate Top Housing Motor Connect Plate Screw and Washers...
  • Page 4: Canopy

    Installation Instruction IMPORTANT:SWITCH OFF THE ELECTRICAL MAINS AT THE MAIN CIRCUIT BREAKER FUSE BOX. Step 1 - Remove the clevis pin,nut and bolt on the rubber pulley. Assemble the canopy and the Coupling Cover on the downrod. Canopy Downrod Coupling Cover Step 2 - Route the safety wire, yellow/green, orange, blue and brown wires through the downrod.
  • Page 5: Bracket

    Installation Instruction Step 3 - The hanger bracket should be screwed on to a CONCRETE CEILING firm flat surface. the fixing location must be able to withstand twenty times the static weight of the fan. If you have any doubts as to the ability of your intended fixing location to be able to withstand this loading.
  • Page 6: Screw

    Installation Instruction Step 5 - 5A) Remove the screws at the motor and fix the blade with the piece to the motor using these screws. 5B) Connect the blue and orange wire from the light kit to the fan motor wire, align the slotted holes on the light kit and tighten back the 3 screws.
  • Page 7: Plate

    Installation Instruction Step 7 - Fix the lamp shade to the fitter plate and twist in. Electrical Connection THERMAL LINK Earth Wire UL1015/AGW 18 (YELLOW/GREEN) UL3321 / AWG 16 (Blue) UL3321 / AWG 16 (Blue) 18W(MAX) E27 18W(MAX) E27 UL3321 / AWG 16 (Orange) UL3321 / AWG 16 (Orange) NOTE: LIGHT BULB USED SHALL NOT EXCEED 18W AND E27 TYPE ONLY.
  • Page 8 1245 mm 49"...
  • Page 9: Blade

    so that the blades are 14. The current carrying wires must be protected by an insulated sleeve and that the wires (inclusive of the sleeve) shall not be subjected to stress. 15. The external earthing conductor should be such that when failure of the suspension system occur, current-carrying conductors become taut before the earthing conductor.
