Page 2
3. Global Access declines all liability caused by improper use or use other than that for which the automated system was intended. 4. Do not install the equipment in an explosive atmosphere: the presence of inflammable gas or fumes is a serious danger to safety.
Specifications Power supply 230VAC - 50Hz Power Absorption (A) Motor Supply 230VAC three phase Motor power 750W Motor RPM 1400 Reduction ratio 1/38 Max Speed 18m/min Working Temperature -20C <> +60C Duty cycle Intensive (70%) IP rating Max thrust 1600N Max gate weight 2200KG Dimensions...
General Information This instruction booklet refers to the Global Access inverter drive sliding gate operator. On initial setup the inverter will learn the travel of the gate by searching for and pushing against the open and closed physical ground stops.
Power Supply Connection The connection for the mains power supply is the 2 pole circuit breaker mounted on the DIN rail IMPORTANT! The unit may not function if connected to a residential Residual Current Device (RCD). The motor should be hard wired to a circuit breaker.
Page 6
Terminals The input/output terminals are located on the side of the mounting bracket next to the inverter. Reset O/S/C Stop Close Safety Common (for terminals 1 to 5 only) *Refer below +24V DC for accessories 0V DC for accessories +24V DC for flashing light 0V DC for flashing light *IMPORTANT- Do NOT use terminal 7 (Common) to power accessories.
Page 7
KEYPAD To change a parameter Press the up or down arrow until the display shows n -- then press enter. Press up or down to select the parameter to be changed then press enter. Press up or down to select the required value then press enter. ...
Input status The status of the inputs can be checked by the following Press the up or down arrow until the display shows P --- then press enter. Press up or down to select P- 39 then press enter. ...
Reset If the motor needs to be initialised after the first setup, bridge a wire between terminals 1 and 7 for 5 seconds. The inverter will relearn the travel limits. Maintenance Maintenance should be performed every 6 months with attention paid to the open and closed physical stops, gear rack and the operation of safety devices.
Page 10
Logic O/S/C Close Stop Safety device “Flip Flop” Closed Opens Partial opening No effect Open Disabled No effect close after pause Opening Closes No effect No effect Stops operation No effect Open Closes Reset timer No effect Stops operation No effect Opens Opens No effect...
